This article provides a detailed overview of the fuse diagrams for the Ford Edge (second generation; CD4 platform): 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024 model years.
Fuses No. 17, 16, 10 and 5 in the block under the hood are responsible for protecting the electrical circuits of the USB outlets and the cigarette lighter.
In the engine compartment
The distribution box is located on the left side of the engine compartment. It consists of two sections: upper and lower.
Upper section of fuse box
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | Description (type 1) | Current, A |
| 1 | Spare | 30 |
| 2 | Starter relay. | - |
| 3 | Rear windshield wiper. Rain sensor, rear washer pump relay coil. | 15 |
| 4 | Fan motor relay. | - |
| 5 | Power Point 3 - Rear of the console. | 20 |
| 6 | Not involved | - |
| 7 | Powertrain control module No. 1. | 20 |
| 8 | Powertrain control module No. 2. | 20 |
| 9 | Powertrain control module relay. | - |
| 10 | Power point 1 - driver's front. | 20 |
| 11 | Powertrain control module No. 4. | 15 |
| 12 |
|
15 |
| 13 | Not involved | - |
| 14 | Not involved | - |
| 15 | Start relay. | - |
| 16 | Power Point 2 - Console | 20 |
| 17 | Power point 4 – luggage compartment. | 20 |
| 18 | 2018: Right HID headlight | 20 |
| from 2019: spare | - | |
| 19 | Electronic power steering at startup. | 10 |
| 20 | 2018: Work/Start lighting. | 10 |
| from 2019: Electric motors for headlight range control | 10 | |
| 21 | 2018: Logical power supply for the gearbox oil pump (start/stop). | 15 |
| from 2019: spare | 15 | |
| 22 | Air conditioning clutch solenoid. | 10 |
| 23 |
|
15 |
| 24 | Spare | 10 |
| 25 | Anti-lock braking system | 10 |
| 26 | Powertrain Control Module | 10 |
| 27 | Not involved | - |
| 28 | Rear washer pump. | 10 |
| 29 | Not involved | - |
| 30 | Not involved | - |
| 31 | Not involved | - |
| 32 | Electronic fan relay 1. | - |
| 33 | Air conditioning clutch relay. | - |
| 34 | Spare | 15 |
| 35 | Not involved | - |
| 36 | Not involved | - |
| 37 | Fan of the power transmission unit. | 10 |
| 38 | Electronic fan relay 2 | - |
| 39 | Electric fan relay 3. | - |
| 40 | Horn relay. | - |
| 41 | 2018: Not involved | - |
| from 2019: Relay for low beam headlights | - | |
| 42 | Fuel pump relay. | - |
| 43 | Electric drive of the 2nd row of seats | 10 |
| 44 | Left HID headlight. | 20 |
| 45 | Not involved | - |
| 46 | Not involved | - |
| 47 | Not involved | - |
| 48 | 2018: Reserve | 15 |
| from 2019: Power supply for steering column lock relay | 15 | |
| 49 | Not involved | - |
| 50 | Sound signal | 20 |
| 51 | Not involved | - |
| 52 | Not involved | - |
| 53 | Not involved | - |
| 54 | Brake switch. | 10 |
| 55 | Generator sensor | 10 |
| 86 | Not involved | - |
| No. | Description (type 2) | Current, A |
| 1 | Spare | 30 |
| 2 | Starter relay | - |
| 3 | Rear windshield wiper. Rain sensor, rear washer pump relay coil | 15 |
| 4 | Fan motor relay. | - |
| 5 | Power point #3 is the back of the console. | 20 |
| 6 | Not involved | - |
| 7 | Engine control module #1 | 20 |
| 8 | Engine control module #2 | 20 |
| 9 | Powertrain control module relay. | - |
| 10 | Power point 1 - driver's front. | 20 |
| 11 | Engine control module #4 | 15 |
| 12 | Engine control module No. 3 | 15 |
| 13 | Not involved | - |
| 14 | Not involved | - |
| 15 | Start relay | - |
| 16 | Power Point 2 - Console | 20 |
| 17 | Power point 4 – in the luggage compartment | 20 |
| 18 | Right HID headlight. | 20 |
| 19 | Electronic power steering | 10 |
| 20 | Turn on the lighting. Headlight range control switch. | 10 |
| 21 | Logical power supply for the gearbox oil pump (start/stop). | 15 |
| 22 | Air conditioning clutch solenoid. | 10 |
| 23 |
|
15 |
| 24 | Spare | 10 |
| 25 | Anti-lock brake system (ABS) | 10 |
| 26 | Powertrain control module at startup | 10 |
| 27 | Not involved | - |
| 28 | Rear washer pump. | 10 |
| 29 | Not involved | - |
| 30 | Not involved | - |
| 31 | Not involved | - |
| 32 | Electronic fan relay #1 | - |
| 33 | Air conditioner electromagnetic clutch relay. | - |
| 34 | Spare | 15 |
| 35 | Not involved | - |
| 36 | Not involved | - |
| 37 | Power transmission fan | 10 |
| 38 | Electronic fan relay #2 | - |
| 39 | Fan relay #3 | - |
| 40 | Horn relay. | - |
| 41 | Not involved | - |
| 42 | Fuel pump relay | - |
| 43 | Power seats 2nd row | 10 |
| 44 | Left HID headlight. | 20 |
| 45 | Not involved | - |
| 46 | Not involved | - |
| 47 | Not involved | - |
| 48 | Steering column lock. | 15 |
| 49 | Not involved | - |
| 50 | Sound signal | 20 |
| 51 | Not involved | - |
| 52 | Not involved | - |
| 53 | Not involved | - |
| 54 | Brake switch. | 10 |
| 55 | Generator sensor | 10 |
Lower section of fuse box
Located on the reverse side.
Access example.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Current, A |
| 56 | Not involved | - |
| 57 | Not involved | - |
| 58 | Fuel pump power supply. | 30 |
| 59 | Electronic fan 3. | 40 |
| 60 | Electronic fan 1. | 40 |
| 61 | Not involved | - |
| 62 | Body control module 1. | 50 |
| 63 | Electronic fan 2. | 25 |
| 64 | Not involved | - |
| 65 | Heated front seat. | 25 |
| 66 | Never used (spare). | 15 |
| 67 | Body control module 2. | 50 |
| 68 | Heated rear window. | 40 |
| 69 | Anti-lock brake system valves. | 30 |
| 70 | Passenger seat. | 30 |
| 71 | Not involved | - |
| 72 | Not involved | - |
| 73 | Heated rear seats. | 20 |
| 74 | Driver's seat module. Electric driver's seat. | 30 |
| 75 | Wiper motor 1 | 25 |
| 76 | Rear door power module. | 30 |
| 77 | Climate controlled seat module. | 30 |
| 78 | Trailer lighting module | 40 |
| 79 | Fan motor | 40 |
| 80 | Windshield wiper motor 2 | 25 |
| 81 | 110V inverter | 40 |
| 82 | Not involved | - |
| 83- | Not involved | - |
| 84 | Starter solenoid | 30 |
| 85 | Not involved | - |
| 87 | Anti-lock brake pump | 60 |
In the passenger compartment
The distribution box is located behind a protective cover on the left side of the dashboard. It is combined with BCM (body control module).
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | Description (type 1) | Current, A |
| 1 | Not involved | - |
| 2 | power inverter logic, sunroof logic, and driver window switch power. | 10 |
| 3 | Seats with lumbar memory. Wireless charging of accessories (smartphone, tablet) | 7.5 |
| 4 | Subwoofer amplifier. | 20 |
| 5 | Not involved | - |
| 6 | Reserve | 10 |
| 7 | Gear shift module. | 10 |
| 8 | Rear door power module. Hands-free rear door open/close module. Built-in modem. | 5 |
| 9 | Keyboard. | 5 |
| 10 | Not involved | - |
| 11 | Not involved | - |
| 12 | Climate control module. Improved central gateway module. | 7.5 |
| 13 | Instrument panel. Steering column control module. | 7.5 |
| 14 | Reserve | 15 |
| 15 | SYNC module or data link power | 15 |
| 16 | Not involved | - |
| 17 | Headlight control module. | 7.5 |
| 18 | Reserve | 7.5 |
| 19 | Reserve | 5 |
| 20 | Push-button ignition switch. | 5 |
| 21 | Temperature and humidity sensor in a car. | 5 |
| 22 | Reserve | 5 |
| 23 | Driver's door glass and mirror. Driver's door module. Driver's door lock indicator. Illuminated driver lock switch. | 30 |
| 24 | Sunroof. | 30 |
| 25 | Audio amplifier | 20 |
| 26 | Window regulator and rear view mirror of the front passenger door. Front passenger door module. Front passenger door lock indicator. Front passenger switch illumination. | 30 |
| 27 | Reserve | 30 |
| 28 | Reserve | 30 |
| 29 | Enhanced central gateway power supply – OBD connector. | 15 |
| 30 | Reserve | 5 |
| 31 | Radio transceiver module. Multifunction display. Integrated control panel. | 10 |
| 32 | Radio. | 20 |
| 33 | Not involved | - |
| 34 | Start-up bus (fuses numbered 17,18, 21, 22, 35, 36, 37, circuit breaker 38). | 30 |
| 35 | Passenger airbag deactivation indicator. | 5 |
| 36 | Rear seat heating module. | 15 |
| 37 | Heated steering wheel. Auto-dimming interior mirror. Automatic high beam and lane departure mirror module. | 20 |
| 38 | Circuit breaker. Right rear power window. Left rear power window. | 30 |
| No. | Description (type 2) | Current, A |
| 1 | Interior lighting (glove box, ceiling). Battery saving relay coil. second row seat relay coil | 10 |
| 2 | Seats with lumbar memory. Logical power supply for the driver's seat module. | 7.5 |
| 3 | Unlocking the driver's door. | 20 |
| 4 | Reserve | - |
| 5 | Reserve | - |
| 6 | Reserve | - |
| 7 | Reserve | - |
| 8 | Reserve | - |
| 9 | Reserve | - |
| 10 | Keyboard. Logical power supply for the rear door module. Hands-free rear door opening module. | 5 |
| 11 | Reserve | 5 |
| 12 | Climate control module. | 7.5 |
| 13 | Dashboard. Steering column control module. Intelligent data link (gateway) connector module. | 7.5 |
| 14 | Extended power module. | 10 |
| 15 | Data transmission channel power. | 10 |
| 16 | Reserve | 15 |
| 17 | Reserve | 5 |
| 18 | Push-button start switch. | 5 |
| 19 | Extended power module. | 7.5 |
| 20 | Reserve | 7.5 |
| 21 | Humidity and temperature sensor in the cabin. | 5 |
| 22 | Passenger presence detection system. | 5 |
| 23 | Delay accessory (power inverter logic, sunroof logic, driver window switch power). | 10 |
| 24 | Unlocking the central lock. | 20 |
| 25 | Driver's door (power window, rear view mirror). Driver's door module. Driver's door lock indicator. Illuminated driver's door lock switch. | 30 |
| 26 | Front passenger door (power window, rear view mirror). Front passenger door module. Front passenger door lock indicator. Illuminated front passenger switch (window, lock). | 30 |
| 27 | Sunroof | 30 |
| 28 | Audio amplifier | 20 |
| 29 | Reserve | 30 |
| 30 | Reserve | 30 |
| 31 | Reserve | 15 |
| 32 | Satellite navigation system. Central display. Voice control (SYNCHRONIZATION). Radio receiving and transmitting module. | 10 |
| 33 | Radio. | 20 |
| 34 | Start-up bus (fuse 19,20,21,22,35,36,37, circuit breaker 38). | 30 |
| 35 | Reserve | 5 |
| 36 | Auto-dimming rearview mirror. Heated seat. Automatic high beam/lane departure mirror module. Power supply for the logic of the rear seat heating module. | 15 |
| 37 | Steering wheel heating module. Active front steering. | 20 |
| 38 | Rear electric windows. Rear window light switch. | 30 |
