The second-generation Ford Galaxy (EUCD platform; chassis code WA6) was produced from 2006 through 2016 with both petrol and diesel engines, undergoing a mid-cycle facelift during its production run. This manual details the Mk2 Ford Galaxy fuse boxes and relay panels, complete with circuit diagrams and layout photos. The fuse assigned to the “Cigarette lighter” is highlighted in bold.
Fuse and relay assignments may vary depending on the model year and equipment specification of your vehicle.
Passenger Compartment Fuse Box
Located underneath the glove box. Turn the two retaining screws counter-clockwise to release and access the fuse panel.
Type 1
General overview.
| Diagram and layout | |
|---|---|
|
|
| No. | Circuit Protected |
| F1 | 5 A Rain sensor |
| F2 | 10 A Supplemental Restraint System (SRS/Airbags) |
| F3 | 5 A ABS, yaw rate sensor (ESP), Electric Parking Brake (EPB), accelerator pedal module |
| F4 | 7.5 A Main power supply, accelerator pedal sensor, electronic fuse module |
| F5 | 15 A Rear window wiper |
| F6 | 15 A Audio system |
| F7 | 7.5 A Steering column control module |
| F8 | 5 A Instrument cluster |
| F9 | 15 A Main-beam headlights |
| F10 | 20 A Sunroof / Panoramic roof |
| F11 | 7.5 A Reversing lights |
| F12 | Spare |
| F13 | 15 A Front fog lights |
| F14 | 15 A Windscreen washer pump |
| F15 | 10 A Adaptive Cruise Control (ACC) |
| F16 | Spare |
| F17 | 10 A Interior courtesy lighting |
| F18 | 5 A Passive Anti-Theft System (PATS / Engine immobiliser) |
| F19 | 15 A Cigarette lighter |
| F20 | Spare |
| F21 | 5 A 2006–2007: Audio unit, rain sensor 5 A 2008–2009: Remote keyless receiver, interior motion sensor |
| F22 | 7.5 A / 20 A Fuel pump module |
| F23 | Spare |
| F24 | 5 A Ignition switch |
| F25 | 10 A Fuel filler flap release |
| F26 | 5 A Battery-backed alarm sounder, OBD II diagnostic port |
| F27 | 5 A Steering column module, climate control panel |
| F28 | 5 A Brake light switch |
| Fuse F19 (15 A) powers the cigarette lighter. | |
Type 2
General overview.
| Diagram and layout | |
|---|---|
|
|
| No. | Circuit Protected |
| F1 | 7.5 A Steering column control module |
| F2 | 5 A Instrument cluster |
| F3 | 10 A Interior courtesy lamps |
| F4 | 5 A Engine immobiliser (PATS) |
| F5 | 7.5 A Adaptive Cruise Control (ACC) |
| F6 | 5 A Rain sensor |
| F7 | 15 A / 20 A Cigarette lighter |
| F8 | 10 A Fuel filler flap unlock circuit |
| F9 | 15 A Rear window washer pump |
| F10 | 15 A Front windscreen washer pump |
| F11 | 10 A Tailgate release actuator circuit |
| F12 | 10 A Fuel filler flap lock circuit |
| F13 | 20 A Fuel pump |
| F13 | 7.5 A / 20 A Fuel pump (2.2L Duratorq-TDCi Euro 5 / Stage V) |
| F14 | 5 A Remote keyless receiver, interior motion sensor |
| F15 | 5 A Ignition switch |
| F16 | 5 A Battery-backed alarm sounder, OBD II diagnostic port |
| F17 | 5 A Steering wheel haptic motor (Lane Keeping Aid) |
| F18 | 10 A SRS (Airbag system) power supply |
| F19 | 7.5 A ABS, yaw rate sensor (ESP), Electric Parking Brake (EPB), accelerator pedal module power supply |
| F20 | 7.5 A Main electronic power supply, electronic fuse module, auto-dimming rear-view mirror, Lane Departure Warning system |
| F21 | 15 A Audio system (including voice control module) |
| F22 | 5 A Brake light switch |
| F23 | 20 A Sunroof / Panoramic roof |
| F24 | 5 A Steering column module, climate control panel |
| Fuse F7 (15 A or 20 A) powers the cigarette lighter. | |
Engine Compartment Fuse Box
Located on the left-hand side of the engine bay under a protective plastic cover.
Location overview.
| Diagram and layout | |
|---|---|
|
|
| No. | Circuit Protected |
| F1 | 10 A / 15 A Transmission Control Module (TCM) |
| F2 | 5 A Glow plug control module |
| F3 | 70 A / 80 A Twin engine cooling fan (2.3L Duratec-HE & 2.2L Duratorq-TDCi automatic), Electro-Hydraulic Power Steering (EHPAS) |
| F4 | 60 A Glow plugs |
| F5 | 60 A / 70 A Engine cooling fan (1.6L Duratorq-TDCi, 2.0L Duratorq-TDCi, 2.0L Duratorq-TDCi Euro 5, 2.2L Duratorq-TDCi manual, 2.0L Duratec-HE, 2.3L Duratec-HE, and 2.0L EcoBoost SCTi); Twin cooling fan (1.6L EcoBoost SCTi) |
| F6 | 7.5 A / 10 A HEGO sensor, CMS sensor, heated oxygen sensors 20 A Fuel vaporizer glow plug |
| F7 | 5 A Solenoid relay coils |
| F8 | 10 A / 15 A / 20 A Powertrain Control Module (PCM), fuel metering valve, MAF sensor, fuel rail pressure control valve (engine management system) |
| F9 | 7.5 A / 10 A / 15 A Active grille shutter, T-MAF sensor, bypass valve, relay coils, auxiliary coolant pump, MAF sensor, EGR valve, fuel vaporizer pump |
| F10 | 7.5 A / 10 A Engine Control Module (2.0L Duratorq-TDCi), auxiliary coolant pump (1.6L EcoBoost SCTi) |
| F11 | 10 A Engine management system (PCV valve, VCV valve, water-in-fuel sensor, EVAP purge valve, swirl control valve, IVVT oil control valve, T-MAF sensor, variable exhaust valve timing, active grille shutter, canister purge valve, turbocharger control valve, boost pressure regulator) 7.5 A Fuel rail pressure sensor, fuel metering valve, active grille shutter (2.2L Duratorq-TDCi Euro 5) 10 A Turbocharger control valve, MAF sensor, active grille shutter, EGR valve, VCV valve (1.6L Duratorq-TDCi) |
| F12 | 10 A Ignition coils, EVAP canister purge valve, power steering pressure sensor (engine management system) |
| F12 | 10 A EGR throttle, variable geometry turbocharger control system (2.0L Duratorq-TDCi) 5 A Relay coils 15 A Ignition coils |
| F13 | 15 A Air conditioning system |
| F14 | 15 A Diesel fuel filter heater (2.0L Duratorq-TDCi, 2.0L Duratorq-TDCi Euro 5, and 1.6L Duratorq-TDCi) 10 A Heated oxygen sensors (2.2L Duratorq-TDCi Euro 5) |
| F15 | 40 A Starter relay supply |
| F16 | 80 A Auxiliary PTC heater (Diesel) |
| F17 | 60 A Central fuse box supply A |
| F18 | 60 A Central fuse box supply B |
| F19 | 60 A Central fuse box supply C |
| F20 | 60 A Central fuse box supply D |
| F21 | 30 A Voltage Quality Module (VQM) / Non-VQM: Instrument cluster, audio unit, climate control module, Start-Stop system (FLR) |
| F22 | 30 A Front windscreen wiper module |
| F23 | 25 A / 30 A Heated rear screen |
| F24 | 30 A Headlamp washers |
| F25 | 30 A ABS control valves |
| F26 | 40 A ABS pump motor |
| F27 | 25 A / 30 A Fuel-fired auxiliary heater |
| F28 | 40 A Climate control blower fan |
| F29 | Spare |
| F30 | 5 A ABS module (terminal 30 feed) |
| F31 | 15 A Horn |
| F32 | 5 A Fuel-fired heater remote receiver module |
| F33 | 5 A Lighting control module, engine compartment fuse box solenoids |
| F34 | 40 A Heated windscreen (left-hand side) |
| F35 | 40 A Heated windscreen (right-hand side) |
| F36 | 5 A ABS module 15 A Rear window wiper power supply |
| F37 | 7.5 A / 10 А Heated windscreen washer jets |
| F38 | 5 A Adaptive Cruise Control (ACC) 10 A PCM / TCM / EHPAS power supply |
| F39 | 15 A Adaptive Front-lighting System (AFS) |
| F40 | 5 A Headlamp leveling module / Adaptive Front-lighting System (AFS) |
| F41 | 20 A Instrument cluster module |
| F42 | 10 A Powertrain Control Module (PCM), Transmission Control Module (TCM), Electro-Hydraulic Power Steering (EHPAS) 5 A Instrument cluster |
| F43 | 5 A Headlamp leveling / AFS module 15 A Audio unit, Brake Vacuum Control module (BVC), DAB digital radio tuner |
| F44 | 20 A Electro-hydraulic power steering (2.0L Duratorq-TDCi), vacuum pump (2.5L Duratec-ST) 5 A Air conditioning climate control (automatic/manual) |
| F45 | 5 A Rear window wiper, Start-Stop system (FLR) |
| No. | Relay Function |
| R1 | Starter relay |
| R2 | Engine Control Relay (ECR) |
| R3 | Air conditioning compressor clutch relay |
| R4 | Glow plug relay (Diesel models) |
| R5 | Engine cooling fan relay |
| R6 | Heated windscreen relay |
| R7 | Ignition relay (Terminal 15) |
| R8 | Windscreen wiper high/low speed relay |
| R9 | Horn relay |
| R10 | Headlamp washer relay |
| R11 | Windscreen wiper ON/OFF relay |
| R12 | Automatic transmission shift lock relay |
Luggage Compartment Fuse Box
Located behind the side access panel in the luggage compartment.
Location overview.
| Diagram and layout | |
|---|---|
|
|
| No. | Circuit Protected |
| FA1 | 25 A Front left door module (power windows, central locking, folding mirrors, heated mirrors) |
| FA2 | 25 A Front right door module (power windows, central locking, folding mirrors, heated mirrors) |
| FA3 | 25 A Rear left door module (power windows) |
| FA4 | 25 A Rear right door module (power windows) |
| FA5 | 10 A Rear door deadlocks (models without rear door modules) |
| FA6 | 15 A Auxiliary power sockets |
| FA7 | 5 A Solenoid relay coils |
| FA8 | 20 A Keyless entry/start system module (2010–2015) |
| FA9 | 5 A Voltage Quality Module (VQM) relay coils (Start-Stop) (2011–2015) |
| FA10 | 30 A Power driver's seat adjustment (2006–2010) |
| FA11 | 20 A Accessory socket, trailer module supply |
| FA12 | 30 A Power driver's seat adjustment (2011–2015) |
| FB1 | 15 A Panoramic roof blind (2011–2015) 5 A Parking aid module, Blind Spot Information System (BLIS) (2006–2010) |
| FB2 | 15 A Continuously Controlled Damping (CCD) suspension module |
| FB3 | 15 A Heated driver's seat |
| FB4 | 15 A Heated front passenger seat |
| FB5 | Spare |
| FB6 | 10 A Rear passenger climate control panel |
| FB7 | Spare |
| FB8 | 5 A Parking aid module, Blind Spot Information System (BLIS) (2011–2015) 10 A Panoramic roof blind |
| FB9 | 30 A Power front passenger seat adjustment |
| FB10 | 10 A Anti-theft alarm siren |
| FB11 | Spare |
| FB12 | Spare |
| FC1 | 7.5 A Power rear quarter vent windows |
| FC2 | 30 A Electric Parking Brake (EPB) |
| FC3 | 30 A Electric Parking Brake (EPB) |
| FC4 | 10 A Rear air conditioning control |
| FC5 | 20 A Keyless start system (2011–2015) 7.5 A Rear seat entertainment / CD changer (2006–2010) |
| FC6 | 20 A Rear air conditioning blower motor |
| FC7 | 5 A Seat memory module |
| FC8 | 7.5 A Rear seat entertainment / CD changer (2011–2015) 20 A Keyless start system (2010) |
| FC9 | 20 A Premium audio amplifier |
| FC10 | 10 A Premium Sony audio system |
| FC11 | Spare |
| FC12 | Spare |
