The second-generation Ford Kuga was produced from 2012 through 2019. During its production run, the model underwent a mid-cycle facelift. This guide provides detailed descriptions, diagrams, and photos of the Ford Kuga Mk2 (C1 / Global C platform; chassis code C520) fuse and relay boxes. The fuse responsible for the “cigarette lighter” is highlighted in bold.
Note: The fuse box layout and component assignments may vary depending on the model year and equipment level of your Ford Kuga Mk2.
In the engine compartment
The engine compartment fuse box is located on the left side of the engine bay and is protected by a cover. To remove the under-hood fuse box cover on the Ford Kuga Mk2, release the retaining latches on the rear of the housing, then pull the cover up and toward you. A diagram showing the current fuse layout is printed on the inside of the cover.
Fuse box layout
| Diagram | |
|---|---|
|
|
| No. | Description |
| F1 | Not used |
| F2 | Not used |
| F3 | Not used |
| F4 | Not used |
| F5 | Not used |
| F6 | Not used |
| F7 | 40 A – Anti-lock braking system (ABS), Electronic Stability Control (ESC) |
| F8 | 30 A – Electronic Stability Control (ESC) module |
| F9 | 20 A – Headlamp washer system |
| F10 | 40 A – Climate control fan / Blower motor |
| F11 | 30 A – Voltage Quality Module (VQM), Body Control Module (BCM) |
| F12 | 30 A – Powertrain Control Module (PCM) |
| F13 | 30 A – Starter motor relay |
| F14 | 40 A – Heated windshield (right side) |
| F15 | 20 A – Front cigarette lighter, auxiliary power sockets |
| F16 | 40 A – Heated windshield (left side) |
| F17 | 20 A – Auxiliary heater |
| F18 | Not used |
| F19 | 5 A – Anti-lock braking system (ABS), Electronic Stability Control (ESC) |
| F20 | 15 A – Horn |
| F21 | 5 A – Brake light switch |
| F22 | 15 A – Battery Monitoring System (BMS) |
| F23 | 5 A – Solenoid relays |
| F24 | 5 A – Exterior lighting control switch |
| F25 | Not used |
| F26 | 5 A – Engine management relay coil (gasoline engines) |
| F26 | 15 A – Engine management relay coil, Transmission Control Module (diesel engines) |
| F27 | 15 A – A/C compressor clutch |
| F28 | 5 A – Adaptive Cruise Control (ACC) module (models with Auto Start-Stop) |
| F29 | 25 A – Heated rear window element |
| F30 | Not used |
| F31 | Not used |
| F32 | 15 A – Powertrain Control Module (PCM) |
| F33 | 10 A – Powertrain Control Module (PCM) |
| F34 | 10 A – Powertrain Control Module (PCM) |
| F35 | 15 A – Powertrain Control Module (PCM) |
| F36 | 5 A – Active grille shutter system |
| F37 | 5 A – Passenger Airbag Deactivation (PAD) status indicator |
| F38 | 5 A – Powertrain Control Module (PCM), Transmission Control Module (TCM) |
| F39 | 5 A – Headlamp leveling system, headlamps |
| F40 | 5 A – Electronic Power-Assisted Steering (EPAS) |
| F41 | 20 A – Body Control Module (BCM) |
| F42 | 15 A – Rear window wiper motor |
| F43 | 15 A – Headlamps |
| F44 | 5 A – Adaptive Cruise Control (ACC) module (models without Auto Start-Stop) |
| F45 | 10 A – Heated windshield washer jets |
| F46 | 40 A – Windshield wiper motor module |
| F47 | Not used |
| F48 | 15 A – Diesel fuel vaporizer system |
| R1 | Not used |
| R2 | Horn relay |
| R3 | Diesel fuel vaporizer relay |
| R4 | Not used |
| R5 | Not used |
| R6 | Not used |
| R7 | Heated windshield power relay |
| R8 | Not used |
| R9 | Headlamp washer relay |
| R10 | Starter motor relay |
| R11 | A/C compressor clutch relay |
| R12 | Engine cooling fan power relay |
| R13 | Blower motor relay (mini relay) |
| R14 | Engine control module (PCM) relay |
| R15 | Heated rear window power relay |
| R16 | Ignition power relay |
| Fuse F15 (20 A) powers the Ford Kuga cigarette lighter and auxiliary sockets. | |
In the passenger compartment
The passenger compartment fuse box is located beneath the glove box on the front passenger side.
Fuse box location
| Diagram | |
|---|---|
|
|
| No. | Circuit Protected |
| 56 | 20 A – Fuel pump module |
| 57 | Not used |
| 58 | Not used |
| 59 | 5 A – Passive Anti-Theft System (PATS) transceiver |
| 60 | 10 A – Interior courtesy lamps, driver door switch pack, glove box lighting, overhead console switch pack |
| 61 | Not used |
| 62 | 5 A – Rain sensor / automatic wipers, auto-dimming rearview mirror |
| 63 | 10 A – Adaptive Cruise Control (ACC) forward sensing module |
| 64 | Not used |
| 65 | 10 A – Power liftgate / tailgate latch release |
| 66 | Not used |
| 67 | 7.5 A – Ford SYNC module, multifunction display, GPS module |
| 68 | 15 A – Electronic steering column lock |
| 69 | 5 A – Instrument cluster |
| 70 | Not used |
| 71 | 10 A – Climate control module (manual A/C or Dual-Zone Electronic Automatic Temperature Control - DEATC) |
| 72 | 7.5 A – Steering wheel control module |
| 73 | 5 A – Data Link Connector (OBD-II port), battery-backed alarm horn |
| 74 | 15 A – High-beam headlamps |
| 75 | 15 A – Front fog lamps |
| 76 | 10 A – Reversing lamps |
| 77 | 20 A – Windshield washer pump |
| 78 | 5 A – Ignition switch, push-button start switch |
| 79 | 15 A – Audio unit, navigation module, touchscreen display, hazard warning light switch, central locking switch |
| 80 | 20 A – Power sunroof / moonroof |
| 81 | 5 A – RF receiver, interior motion alarm sensor |
| 82 | 20 A – Rear window washer pump |
| 83 | 20 A – Central locking system |
| 84 | Not used |
| 85 | 7.5 A – Ignition switch module |
| 86 | 10 A – Restraints Control Module (airbags), occupant classification system, passenger airbag deactivation (PAD) indicator |
| 87 | Not used |
| 88 | Not used |
| 89 | Not used |
In the luggage compartment
The luggage compartment fuse box is located behind the side trim panel in the cargo area and is protected by a removable cover.
Fuse box location
| Diagram | |
|---|---|
|
|
| No. | Description |
| F1 | 5 A – Hands-free power liftgate / tailgate sensor system |
| F2 | 10 A – Remote Keyless Entry (RKE) module |
| F3 | 5 A – Keyless entry door handles |
| F4 | 25 A – Front left door control module |
| F5 | 25 A – Front right door control module |
| F6 | 25 A – Rear left door control module |
| F7 | 25 A – Rear right door control module |
| F8 | Not used |
| F9 | 25 A – Driver seat power adjustment motor |
| F10 | Not used |
| F11 | 5 A – Ignition relay coil (rear fuse box) |
| F12 | 10 A – Climate control module (models with Auto Start-Stop) |
| F13 | 5 A – Instrument cluster (models with Auto Start-Stop) |
| F14 | 7.5 A – Multifunction display, Ford SYNC module, GPS module (models with Auto Start-Stop) |
| F15 | 15 A – Audio unit (models with Auto Start-Stop) |
| F16 | Not used |
| F17 | Not used |
| F18 | Not used |
| F19 | Not used |
| F20 | Not used |
| F21 | Not used |
| F22 | Not used |
| F23 | Not used |
| F24 | 30 A – Auxiliary AC/DC power outlets |
| F24 | 20 A – Rear auxiliary power outlets |
| F25 | 25 A – Power liftgate / tailgate motor |
| F26 | 40 A – Trailer tow control module / accessories |
| F27 | 20 A – Cargo area auxiliary power socket |
| F28 | Not used |
| F29 | 5 A – Blind Spot Information System (BLIS), front camera sensor, adaptive cruise control, rear-view camera, Voltage Quality Module ignition signal |
| F30 | 5 A – Parking aid module |
| F31 | Not used |
| F32 | 5 A – Ignition signal for AC/DC power outlets |
| F33 | Not used |
| F34 | 20 A – Heated driver seat |
| F35 | 20 A – Heated front passenger seat |
| F36 | Not used |
| F37 | Not used |
| F38 | Not used |
| F39 | Not used |
| F40 | Not used |
| F41 | Not used |
| F42 | Not used |
| F43 | Not used |
| F44 | Not used |
| F45 | Not used |
| F46 | 10 A – Blind Spot Information System (BLIS), front camera sensor, adaptive cruise control, rear-view camera (models with Auto Start-Stop) |
| R1 | Ignition switch power relay |
| R2 | Not used |
| R3 | Not used |
| R4 | Not used |
| R5 | Not used |
| R6 | Not used |
