This article provides detailed fuse and relay box diagrams for the Geely CK (also marketed as the Gleagle Echo, 1st generation) for model years 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, and 2016.
Fuse F17 protects the cigarette lighter electrical circuit.
Engine Compartment
The engine compartment contains two power distribution boxes that protect the vehicle’s electrical system.
Main Power Distribution Box
Located on the left side beneath the protective cover.
General layout view.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit / Component Protected | Rating (A) |
| R1 | Heater blower relay | |
| R2 | Fuel pump relay | |
| R3 | Engine main relay | |
| R4 | A/C condenser fan relay | |
| R5 | A/C system relay | |
| R6 | A/C compressor clutch relay | |
| R7 | Radiator cooling fan relay | |
| R8 | Fog light relay | |
| R9 | Horn relay | |
| S1 | Heater blower motor | 20 |
| S2 | Radiator cooling fan | 20 |
| S3 | A/C condenser fan | 20 |
| S4 | Ignition switch | 30 |
| S5 | Ignition switch | 30 |
| S6 | Electronic Stability Control (ESC/ESP) | 30 |
| S7 | Power windows | 30 |
| S8 | Heated rear window | 20 |
| F1 | Central door locking | 20 |
| F2 | Anti-theft alarm system | 15 |
| F3 | Brake lights | 10 |
| F4 | Interior lighting, door courtesy lamps, audio memory | 10 |
| F5 | Parking / side marker lights | 15 |
| F6 | Fuel pump | 20 |
| F7 | Spare | 20 |
| F8 | Right headlight | 10 |
| F9 | Left headlight | 10 |
| F10 | Horn | 15 |
| F11 | Body Control Module (BCM) | 10 |
| F12 | Engine Control Module (ECM) and OBD-II diagnostic port | 10 |
| F13 | A/C compressor clutch | 10 |
| F14 | Anti-lock Braking System (ABS) | 15 |
| F15 | Front fog lights | 15 |
| F16 | Audio system, power side mirrors | 10 |
| F17 | Cigarette lighter | 20 |
| F18 | Supplemental Restraint System (SRS / Airbags) | 10 |
| F19 | Instrument cluster | 10 |
| F20 | Windshield wipers | 15 |
| F21 | Reverse lights | 10 |
| F22 | Engine management, ignition coils | 15 |
| F23 | Alternator | 10 |
Auxiliary Power Distribution Box
Located adjacent to the positive battery terminal.
Circuit assignments:
- 1 — Blower motor / Heater (80 A)
- 2 — Alternator (80 A)
- 3 — Anti-lock Braking System / ABS (50 A)
