Fuses Geely Emgrand (EC7; 2009–2018)

This guide provides detailed fuse box diagrams and circuit descriptions for the first-generation Geely Emgrand EC7 (model years 2010, 2011, 2012, 2013, 2014, 2015, 2016, and 2017).

Fuse No. 6 in the passenger compartment fuse box protects the cigarette lighter circuit.

Engine Compartment Fuse Box

The fuse box is located on the left side of the engine bay, near the battery. Remove the protective cover to access the fuses.

General layout view.

Fuse Box Diagram
Fuse No.	Protected Circuit / Function	Rating (A)
F01	Downstream oxygen sensor (O2)	5 A
F02	Upstream oxygen sensor (O2)	5 A
F03	Engine control system	30 A
F04	Starter motor relay	30 A
F05	Alternator control	10 A
F06	Right low-beam headlight	10 A
F07	Right high-beam headlight	10 A
F08	Left low-beam headlight	10 A
F09	Power windows	30 A
F10	Main battery supply	60 A
F11	Ignition switch (AM1)	30 A
F12	Engine Control Module (ECM)	10 A
F13	Daytime running lights (DRL)	15 A
F14	Fuel pump	15 A
F15	Unassigned	15 A
F16	Left high-beam headlight	10 A
F17	Alternator main feed	100 A
F18	Front fog lights	15 A
F19	Anti-lock braking system (ABS)	25 A
F20	Unassigned	25 A
F21	Heated seats	15 A
F22	Unassigned	30 A
F23	Ignition switch (AM2)	30 A
F24	Radiator cooling fan motor	40 A
F25	Power seat adjustment	30 A
F26	Rear window defroster	30 A
F27	Main battery supply	60 A
F28	Ignition feed (IG1)	40 A
F29	Radiator cooling fan	40 A
F30	Anti-lock braking system (ABS) pump	40 A

Passenger Compartment Fuse Box

The fuse box is located on the driver’s side of the dashboard, behind the lower access panel.

Location overview shown for reference.

Fuse Box Diagram
Fuse No.	Protected Circuit / Function	Rating (A)
1	Reverse lights	10 A
2	Anti-lock braking system (ABS) module	10 A
3	Engine Control Module (ECM)	10 A
4	Supplemental Restraint System (Airbag / SRS)	10 A
5	Auxiliary power outlet (12V socket)	15 A
6	Cigarette lighter	15 A
7	Power sunroof control module	10 A
8	Windshield wipers and washer	20 A
9	Instrument cluster	10 A
10	Body Control Module (BCM)	10 A
11	Rear window wiper	10 A
12	Ignition coils	15 A
13	Audio system / Head unit	15 A
14	Rear fog light	10 A
15	Security alarm siren	10 A
16	A/C compressor clutch	10 A
17	Power sunroof motor	30 A
18	Heated side mirrors	10 A
19	Horn
20	Brake lights	10 A
21	Battery protection / saver module	15 A
22	Parking lights / Position lamps	10 A
23	Power door locks	20 A
24	On-Board Diagnostics connector (OBD II)	10 A
25	Hazard warning lights	10 A
26	Headlight switch / Lighting control	10 A
