Hyundai i40 is a family car, produced in 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019 with both diesel and gasoline engines. During this time, the model has been restyled. In this article you will find a description of the fuses and relays of the Hyundai i40 with block diagrams and their locations. Note the cigarette lighter fuse.
The design of the blocks and the purpose of the elements in them may differ from that shown and depends on the year of manufacture and the level of equipment. Check the description with your diagrams on the back of the protective cover.
In the passenger compartment
It is located at the bottom of the dashboard; remove the protective cover to access.
General view.
| Diagram | |
|---|---|
|
|
| Name | Description |
| POWER OUTLET 2 | Console power outlet, rear power outlet |
| POWER TAIL GATE | Electric boot lid |
| MODULE 1 | Electronic key control unit, BCM, audio system, amplifier, JBL AMP, audio-visual head unit with navigation, DC / DC converter (audio system / amplifier), ceiling lamp of the console, parking aid, electric door mirror switch |
| MODULE 4 | Relay and fuse box m / o (relay 12), brake light switch, multi-function diagnostic connector, active choke device, fuel filter warning sensor (D4FD) |
| MODULE 3 | Electronic key control unit, BCM, panoramic sunroof, rain sensor, driver / passenger CCS control module, ICM relay box (headlight washer relay) |
| POWER OUTLET 1 | Front power outlet |
| P / SEAT PASS | Passenger side manual switch |
| HTD MIRR | Outside mirror with electric drive on the driver / passenger side, ECM / R CM, air conditioning control unit |
| AMP | Amplifier, JBL AMP, DC to DC Converter (amplifier) |
| WIPER FRT | ICM relay box (rain sensor relay), multi function switch, under-hood fuse / relay box (relay 7), windshield wiper motor |
| A / CON | Engine compartment relay and fuse box (relay 4), EMS unit (fuel heater relay), diesel unit (heater relay with PTC No. 2 / No. 3), air conditioning control unit |
| STEERING WHEEL HEATER | Steering wheel heater |
| P / WDW LH | Relay left door lift glass, main switch driver / passenger power lift glass, anti-pinch power lift glass module, anti-pinch rear left power lift glass module, rear left power lift glass module |
| PDM 1 | Tailgate Release Relay, Tailgate Latch (Saloon), Power Tailgate Latch / Trunk Latch (Estate), ICM Relay Box (Fuel Filter Lock / Unlock Relay) |
| P / SEAT DRV | Driver IMS unit, driver side manual switch |
| MODULE 2 | BCM, immobilizer module, converter (audio / amplifier), audio system, electrochromic mirror, lane keeping assist system module, air conditioning control module, headlight left / right, driver IMS module, headlight range control device, portable lamp, headlight beam throw adjustment drive (left / right), rear left / right seat heater, tire pressure monitor module, driver / passenger CCS control module, automatic transmission selector lever indicator, console switch, driver / passenger seat heating module |
| WIPER RR | Rear wiper relay, rear wiper motor, multi function switch, rear blind module |
| BRAKE SWITCH | Brake light switch |
| P / WDW RH | Relay RH door lifter glass, Main switch driver / passenger power lift glass, anti-pinch power lift glass module, anti-pinch power rear right lift glass module, rear right power lift glass module |
| PDM 2 | Electronic key control unit, start and stop button, immobilizer module |
| MODULE 5 | Driver / Passenger Electric Key Outside Handle, Driver / Passenger Power Outside Mirror, Active Choke, Left / Right Rear Seat Heater Switch, Auto Light Sensor and Photocell, Sport Mode Switch, Key Solenoid |
| IG1 | Relay and fuse box m / o (fuse F27, F28, F29, F30, F31) |
| MODULE 6 | Instrument panel, front left / right seat heater switch, front adaptive lighting module, electric parking brake module |
| MDPS | EPS control unit |
| DR LOCK | Door Lock / Unlock Relay, ICM Relay Box (Dual Lock Relay), Passenger / Driver Side Door Lock Actuator, Rear Left / Right Door Lock Actuator |
| S / HEATER FRT | Driver / passenger seat CCS control unit, driver / passenger seat heater control unit |
| INTERIOR LAMP | Driver / Passenger Door Lamp, Roof Console Lamp, Portable Lamp, Ceiling Lamp, Glove Compartment Lamp, Trunk Lamp, Driver / Passenger Step Lamp, Trunk Lamp, Rear L / R Trim Lamp, Sun Visor Lamp L / R driver |
| MULTI MEDIA | Audio system, audio-visual head unit with navigation, converter (audio system) |
| A / BAG | SRS control unit |
| CURTAIN | Rear curtain module |
| MEMORY 1 | Instrument cluster, tire pressure monitoring module, rear curtain module, tilt sensor, air conditioning control module, BCM, ultrasonic sensor for protection against unauthorized access to the passenger compartment, driver IMS siren module, electric outside mirror switch |
| A / BAG IND | Instrument cluster |
| PDM 3 | Electronic key control unit |
| S / HEATER RR | Rear Seat Heater Unit (Left / Right) |
| MEMORY 2 | Radio receiver |
| PDM 1 | Electronic key control unit |
| START | Without start button: engine compartment relay and fuse box (relay 8), ignition switch, automatic transmission range switch; with start button: ECM / PCM, automatic transmission range switch |
| SUNROOF | Panoramic sunroof |
The fuses designated as POWER OUTLET are responsible for the cigarette lighter and additional sockets.
In the engine compartment
Primaty fuse box
Located on the left side of the engine compartment.
General view.
| Diagram | |
|---|---|
|
|
| Name | Description |
| MDPS | EPS control unit |
| B + 1 | Junction box l / P (IPS 0 (4CH), IPS 1 (4CH), IPS 2 (2CH), fuse F13 / F14 / F19 / F20 / F21 / F26 / F36) |
| ABS 1 | ESP control unit, multi-functional diagnostic socket |
| ABS 2 | |
| IG 2 | Relay 9 (start relay), ignition switch (without start button), relay 6 (relay MRP 4 (ZAZH.2), with start button) |
| BLOWER | Relay 4 (fan relay) |
| RR HTD | Relay 11 (rear window defogger relay) |
| B + 2 | Junction box l / P (IPS 3 (4CH), IPS 4 (4CH), fuse F2 / F7 / F9 / F15) |
| AMP | Amplifier, converter (amplifier) |
| EPB 1 | Parking brake electric module |
| EPB 2 | Parking brake electric module |
| C / FAN | Relay 1 (cooling fan relay (low), relay 2 (cooling fan relay (high) |
| FRONT | ICM Relay Box (Heated Windshield Relay) |
| DEICER | Relay 5 (Horn Relay), ICM Relay Box (Heater Relay) |
| HORN | Relay 12 (US relay), brake light relay |
| STOP LAMP | ICM Relay Box (Headlight Washer Relay) |
|
|
Additional block
It is installed on diesel versions of Hyundai i40 on the right side of the engine compartment.
