The ASX is a compact crossover SUV produced by Japanese automaker Mitsubishi Motors, which debuted at the 2010 Geneva Motor Show. In the Japanese domestic market, it was introduced as the RVR, while in North America, it is sold as the Outlander Sport. This article provides comprehensive fuse box diagrams and location guides for the first-generation Mitsubishi ASX / Outlander Sport (chassis codes GA1W / GA2W / GA3W / GA6W / GA8W / GA0; GS platform; model years 2010–2021).
Below are the photos, component layouts, and fuse box diagrams for each power distribution panel. Fuses for critical circuits, such as the “Cigarette Lighter” and “Fuel Pump,” are highlighted in bold.
In the engine compartment
The underhood fuse and relay box is mounted on the left side of the engine compartment, adjacent to the battery. Remove the protective cover to gain access.
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating (A) |
| A | Fog lamp relay | |
| B | Horn relay | |
| C | A/C compressor magnetic clutch relay | |
| D | Auxiliary equipment / Optional relay | |
| E | Automatic transmission control relay | |
| F | Auxiliary equipment / Optional relay | |
| G | High-beam headlamp relay | |
| H | Electronic throttle control relay | |
| I | Auxiliary equipment / Optional relay | |
| J | Daytime running light (DRL) relay | |
| K | Fuel pump relay | |
| L | Auxiliary equipment / Optional relay | |
| M | A/C condenser fan relay | |
| N | Starter relay | |
| O | Low-beam headlamp relay | |
| P | Engine cooling fan relay | |
| R | Auxiliary equipment / Optional relay | |
| S | Engine Control Module (ECM) main relay | |
| T | Auxiliary equipment / Optional relay | |
| Q | Condenser fan relay | |
| 1 | Front fog lamps | 15 |
| 2 | Engine Control Module (ECM) | 7.5 |
| 3 | Automatic transmission control unit (TCU) | 20 |
| 4 | Horn | 10 |
| 5 | Generator / Alternator | 7.5 |
| 6 | Headlamp washers | 20 |
| 7 | Air conditioning system (A/C) | 10 |
| 8 | Electronic throttle body / Oil cooler fan (Twin Clutch SST) | 15 |
| 9 | Anti-theft alarm siren | 20 |
| 10 | Windshield wiper de-icer | 15 |
| 11 | Not used | - |
| 12 | Power liftgate / tailgate | 30 |
| 13 | Daytime running lights (DRL) | 10 |
| 14 | High-beam headlamp (left) | 10 |
| 15 | High-beam headlamp (right) | 10 |
| 16 | Low-beam headlamp (left) [HID / Gas-discharge] | 20 |
| 17 | Low-beam headlamp (right) | 20 |
| 18 | Low-beam headlamp (left) | 10 |
| 19 | Low-beam headlamp (right) | 10 |
| 20 | Engine management power supply circuit | 10 |
| 21 | Ignition coils | 10 |
| 22 | Engine management electrical system / Fuel line heater | 20 / 25 |
| 23 | Fuel pump fuse | 15 |
| 24 | Starter motor solenoid | 30 |
| 25 | Not used | - |
| 26 | Anti-lock Braking System (ABS) / ASC | 40 |
| 27 | Anti-lock Braking System (ABS) / ASC | 30 |
| 28 | Condenser fan motor | 30 |
| 29 | Engine cooling fan motor | 40 |
| 30 | ETACS / I/O control module | 30 |
| 31 | Audio system power amplifier | 30 |
Primary high-current fusible links are located directly on the positive (+) battery terminal.
In the passenger compartment
Located beneath the dashboard on the driver's side. Remove the protective cover to access the panel.
General view of the Mitsubishi ASX / Outlander Sport interior fuse box.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating (A) |
| A | Central door locking relay | |
| B | Heater / Climate control relay | |
| C | Heated seat relay | |
| D | Blower motor fan relay | |
| 1 | Blower motor | 30 |
| 2 | Stop lamps / Brake lights | 15 |
| 3 | Rear fog lamp | 10 |
| 4 | Windshield wipers | 30 |
| 5 | Auxiliary equipment / Option circuits | 10 |
| 6 | Power door locks | 20 |
| 7 | Audio system | 15 |
| 8 | Relay control unit (ETACS) | 7.5 |
| 9 | Interior lighting / Dome lamps | 15 |
| 10 | Hazard warning lamps | 15 |
| 11 | Rear window wiper | 15 |
| 12 | Instrument cluster | 7.5 |
| 13 | Cigarette lighter fuse (Mitsubishi ASX / Outlander Sport) | 15 |
| 14 | Ignition switch | 10 |
| 15 | Power sunroof | 20 |
| 16 | Power exterior mirrors | 10 |
| 17 | Electronically controlled All-Wheel Drive (AWD) system | 10 |
| 18 | Backup / Reverse lamps | 7.5 |
| 19 | 12V accessory power socket | 15 |
| 20 | Power windows | 30 |
| 21 | Rear window defroster / demister | 30 |
| 22 | Heated exterior mirrors | 7.5 |
| 23 | 115V AC power outlet / Inverter | 15 |
| 24 | Power seats | 20 / 25 |
| 25 | Heated seats | 30 |
