The Mitsubishi Eclipse is a four-seat (2+2) sports coupe produced from 1989 to 2011 exclusively in left-hand-drive (LHD) configurations. In the U.S., it was also marketed under the Eagle Talon and Plymouth Laser nameplates. This article provides detailed fuse box diagrams and circuit assignments for the 3rd and 4th generation Mitsubishi Eclipse (chassis codes D52A/D53A and DK2A/DK4A; model years 2000–2005 and 2006–2012).
Below are the locations, diagrams, and descriptions of the power distribution centers and fuse blocks. Fuses for the “Cigarette Lighter” and “Fuel Pump” circuits are highlighted in bold.
In the Engine Compartment
Version 1
Located on the left side of the engine compartment. It consists of the main fuse box and an adjacent auxiliary panel on the left side.
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Protected | Rating (A) |
| R1 | Auxiliary power socket relay | |
| R2 | Horn / security alarm relay | |
| R3 | Headlight washer / air purifier relay | |
| R4 | Horn / security alarm relay | |
| R5 | Front fog lamp relay | |
| R6 | Radiator cooling fan relay | |
| R7 | A/C compressor magnetic clutch relay | |
| R8 | Engine control module (ECM) relay | |
| R9 | Transmission control module (TCM) relay | |
| R10 | Ignition relay | |
| R11 | Electronic throttle control relay | |
| R12 | Spare | |
| R13 | Spare | |
| 1 | Passenger compartment fuse panel / Battery main feeder | 60 / 80 |
| 2 | Radiator cooling fan motor | 50 |
| 3 | Anti-lock Braking System (ABS) | 30 |
| 4 | Ignition switch circuit | 40 |
| 5 | Power windows | 40 |
| 6 | Front fog lamps | 15 |
| 7 | Auxiliary AC power outlets | 15 / 20 |
| 8 | Horn / Warning chime | 10 |
| 9 | Engine management system (EMS) | 20 |
| 10 | A/C compressor magnetic clutch | 10 |
| 11 | Brake lights (Stop lamps) | 15 |
| 12 | Windshield wiper de-icer / Horn circuit | 15 |
| 13 | Generator / Alternator | 7.5 |
| 14 | Security alarm system | 10 |
| 15 | Transmission Control Module (TCM) | 20 |
| 16 | Right headlight (high beam) | 10 |
| 17 | Left headlight (high beam) | 10 |
| 18 | Right headlight (low beam) | 10 |
| 19 | Left headlight (low beam) | 10 |
| 20 | Right taillight | 7.5 |
| 21 | Left taillight | 7.5 |
| 22 | Interior lighting / Dome lamp | 15 |
| 23 | Audio system | 10 |
| 24 | Fuel pump fuse | 15 |
| 25 | Windshield wipers and washers | 30 |
Version 2
Located on the left side of the engine compartment behind the protective cover.
Fuse box cover schematic example.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Protected | Rating (A) |
| A | Instrument panel fuse box (fuses No. 1, 2, 3, 10, 11) | 60 |
| B | Not used | - |
| C | Instrument panel fuse box (fuses No. 17, 19), power windows, power driver's seat, convertible top, audio power amplifier | 30 |
| D | Air conditioning system, radiator cooling fan | 50 |
| E | Anti-lock Braking System (ABS) | 50 |
| F | Convertible top power supply | 30 |
| G | Ignition switch circuit | 30 |
| H | Generator / Alternator circuit (fusible link located on the battery terminal) | 120 |
| 1 | Not used | - |
| 2 | Front fog lamps | 15 |
| 3 | Air conditioning system | 10 |
| 4 | ECU main power supply, dome lamp, trunk lamp, garage door opener transceiver, power sunroof assembly, audio unit, multi-center display, instrument cluster | 10 |
| 5 | Audio system | 10 |
| 6 | Headlamps, anti-theft alarm system | 10 |
| 7 | Headlamps, anti-theft alarm system | 10 |
| 8 | Instrument panel rheostat, taillights, parking lights, rear side marker lights, switch backlighting | 10 |
| 9 | Taillights, parking lamps, rear side turn signal lamps, license plate lamps | 10 |
| 10 | Not used | - |
| 11 | Headlamp | 10 |
| 12 | Headlamp | 10 |
| 13 | INVECS-II 4-speed A/T module, MFI system, A/C system, cooling fan system, engine immobilizer | 20 |
| 14 | Charging system, central door locking (keyless entry models), turn signal lamps, hazard warning lamps | 10 |
Auxiliary Relay Block
In the Passenger Compartment
Version 1
Located on the lower driver's side of the dashboard. Remove the plastic access cover to reach the panel.
Access overview.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Protected | Rating (A) |
| R1 | Fuel pump relay 1 | |
| R2 | Heated front seat relay | |
| R3 | Fuel pump relay 2 | |
| R4 | Auxiliary power socket relay | |
| R5 | Rear fog lamp relay | |
| R6 | Power window relay | |
| R7 | Blower motor relay | |
| R8 | Rear window defogger relay | |
| 1 | Ignition control system | 10 |
| 2 | Instrument cluster | 7.5 |
| 3 | Backup (reverse) lamps, automatic transmission control relay | 7.5 |
| 4 | Cruise control system | 7.5 |
| 5 | Control relays | 7.5 |
| 6 | Power exterior mirrors | 7.5 |
| 7 | Windshield wipers and washers, electronic timing and control module (ETACS) | 30 |
| 8 | Engine Control Module (ECM), Transmission Control Module (TCM - A/T models), fuel pump relay | 7.5 |
| 9 | Cigarette lighter / Auxiliary power outlet | 15 |
| 10 | Spare | - |
| 11 | Power exterior mirrors | 7.5 |
| 12 | Engine Control Module (ECM) | 7.5 |
| 13 | Audio head unit / Radio | 10 |
| 14 | Rear window wiper and washer | 15 |
| 15 | Central power door locking system | 15 |
| 16 | Cigarette lighter / Auxiliary power outlet | 15 |
| 17 | Spare | - |
| 18 | Interior lamps / Dome light | 10 |
| 19 | Climate control blower motor | 30 |
| 20 | Rear window defogger | 30 |
| 21 | Power sunroof motor | 20 |
| 22 | Heated front seats | 20 |
| 23 | Power mirror actuators | 20 |
| 24 | Power sunroof | 15 |
Version 2
Located behind the trim panel on the side of the instrument panel (driver's side).
Access overview.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Protected | Rating (A) |
| R1 | Blower motor relay | |
| R2 | Rear window defogger relay | |
| R3 | Turn signal and hazard flasher relay | |
| 1 | Rear window defogger, heated side mirrors | 30 |
| 2 | Blower motor | 30 |
| 3 | Brake lamps (stop lights) | 15 |
| 4 | SRS control module, turn signal and hazard flasher relay | 15 |
| 5 | Control modules (TCM, ETACS, ECM - 4G93 engine), instrument cluster, backup lamps, navigation system, speed pulse sensors (A/T) | 10 |
| 6 | Audio unit, CD changer, MMCS display, power side mirror controls, digital clock, audio amplifier | 10 |
| 7 | Cigarette lighter fuse | 15 |
| 8 | Windshield wiper and washer, rear window wiper and washer, ETACS control module | 20 |
| 9 | Power sunroof control module, ASC solenoid valve relay, ABS module | 10 |
| 10 | Horn | 10 |
| 11 | Central door locking system, fuel filler flap release | 15 |
| 12 | Ignition switch signal | 10 |
| 13 | Control modules (ETACS, SRS), Vehicle Speed Sensor (VSS), instrument panel rheostat, instrument cluster | 10 |
| 14 | Horn | 10 |
| 15 | Smart Wiring System (SWS) control module | 10 |
| 16 | Blower motor relay, A/C control module, A/C compressor relay, windshield wiper de-icer, rear defogger switch/servos | 10 |
| 17 | Spare | 30 |
| 18 | Spare | 10 |
| 19 | Spare | 15 |
| 20 | Spare | 20 |
Side-mounted inline fuses: Windshield wiper (20A), heated side mirrors (10A), power sunroof control module (20A), audio system (20A).
