Fuses and relays Mitsubishi Montero (Pajero) Sport 1, 1996 - 2008

Pajero Sport is a mid-size SUV of the Japanese company Mitsubishi, debuted in 1996. It was built on the base of L200 pickup truck. In 2000, the model was restyled. In Japan it is sold under the name Challenger, in the U.S. market it is known as Montero Sport. In this article we will understand in detail fuse box diagrams Mitsubishi Montero Sport / Pajero Sport (first generation) 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008  years of manufacture.

Here you will find the locations and photos of the mounting blocks. Also, we will separately mark the fuses responsible for the cigarette lighter and the fuel pump.

In the engine compartment


Location of components.

Power fuse panel

Located near the plus terminal of the battery.


Description:

  • 1 - ABS 60A;
  • 2 - Fog lamps 20A;
  • 3 - Glow plugs 80A.

Primary fuse box


Located on the left side of the engine compartment, next to the battery.


Consists of a main unit and an auxiliary unit.

Diagram

Description Amps
1 Interior lighting 10
2 High beam 10
3 Rear position lights 10
4 Rear position lights 10
5 Hazard 10
6 Climate control system electric fan 30
7 Air conditioner 30
8 Launch system 40
9 Ignition switch (lock) 40
10 Power windows 30
11 Low beam 30
12 Engine control module 20
13 Alternator 80
R1 Electric fan relay of the climate control unit
R2 Headlight relay
R3 Fog lamp relay
R4 Starter relay
R5 Starting system relay

An additional unit is attached next to the main unit.


Description:

  • 1 - Electrical condenser fan 25A;
  • 2 - Air conditioner compressor 10A;
  • A - Spare;
  • B - A / C compressor relay;
  • C - Condenser electric fan relay.

Additional elements


Relay modules can also be installed on the right side of the engine compartment. Description:

  1. Horn relay;
  2. ABS relay.

In the passenger compartment


There are 2 blocks under the dashboard on the driver's side: the fuse box and the relay box.

Fuse box


General view.

Diagram
Desciption Amps
1 Turn indicators 10
2 Audio system 10
3 Central door lock 15
4 Relay of the climate system fan relay 10
5 Mitsubishi Montero cigarette lighter fuse 15
6 Windshield wiper 20
7 Back-up lights 10
8 Instrument cluster 10
9 Stop lamps 10
10 Horn 10
11 Power windows 10
12 automatic transmission 10
13 injection pump 15
14 sunroof 15

Some relay modules may be located in the upper part of the unit.
  • R1 - turn signal relay;
  • R2 - Rear window and side mirror heater relay;
  • R3 - Heater fan motor relay (for L200)

Relay box

Located next to the main unit.

Diagram
Description
1 Ignition switch (lock)
2 socket for connection of additional equipment - relay
3 Rear heater electric motor relay
4 Power windows relay
5 rear window heating 30A
6 Rear heater
7 Relay timer for heated rear door window and exterior mirrors
8 Trunk door wiper relay interrupter
9 outlets for connecting additional equipment 15A
10 heated exterior mirrors 10A


Depending on the model year and equipment level, it is possible to locate individual auxiliary relays and other control units outside of the blocks shown, such as the fuel pump control unit.


Or the rear fog light relay.
