Fuses and relays Nissan Qashqai (J11), 2013 - 2020

The Nissan Qashqai is a compact crossover SUV that entered production in 2006. The Qashqai+2 is a 7-seater variant featuring an extended wheelbase. In the United States, it is marketed as the Rogue Sport. The first generation is designated as the J10 (produced from 2007 through 2012), and the second generation is designated as the J11 (produced from 2013 through 2020). This article provides detailed descriptions, component locations, diagrams, and fuse/relay assignments for the second-generation Nissan Qashqai fuse boxes (chassis code J11; CMF-CD platform). A dedicated section highlighting the cigarette lighter and 12V power outlet fuses is also included.

Note: Fuse box layouts, component counts, and circuit diagrams may vary depending on the country of delivery, model year, and vehicle equipment level. Always cross-reference the diagram printed on the protective cover of your vehicle's fuse box.

Passenger Compartment Fuse Boxes

The interior fuse boxes are located on the end of the instrument panel.

Right-hand fuse box (optional / model-dependent)

Left-hand fuse box (main)

Fuse box location overview

Interior fuse box photograph

Diagram
No.	Description
1	15A Windshield washer pump
2	10A Airbag system (SRS)
3	5A Instrument cluster
4	10A Ignition system
5	10A Vehicle Dynamic Control (VDC)
6	15A Heated seats
7	20A Blower motor / HVAC fan
8	5A Instrument panel, switch, and glove box illumination
9	20A Reserved / Spare
10	15A Rear window defogger
11	15A Heated windshield / Rear window defogger
12	10A Power mirrors
13	10A Vehicle Dynamic Control (VDC / ESC)
14	10A Auxiliary electrical accessories
15	15A Front cigarette lighter / 12V power outlet
16	10A Reserved / Spare
17	20A Blower motor / HVAC fan
18	10A Reserved / Spare
19	20A Audio / Infotainment system
20	5A Electronic control modules
21	10A Instrument cluster
22	10A Interior lighting
23	20A Reserved / Spare
24	10A Stop lamps (Brake lights)
25	10A Immobilizer antenna unit
26	5A Clutch pedal switch / position sensor
27	10A Body Control Module (BCM)
28	10A Electronic control modules
29	20A Power door locks / Central locking system
30	15A Windshield wipers
31	15A Rear 12V accessory socket / cigarette lighter
32	15A Hazard warning lights, turn indicators

The 12V power sockets and cigarette lighter are protected by fuse 15 (front, 15A) and fuse 31 (rear, 15A).

Individual relay units are mounted on the reverse side of the fuse block.

Engine Compartment (Under-Hood)

Under-hood fuse blocks are located in the engine compartment beneath the air intake duct. Accessing the panel is illustrated below.

Photograph of Primary Fuse & Relay Box (IPDM E/R).

Diagram
No.	Description
81	10A Engine Control Module (ECM)
82	15A Engine Control Module (ECM)
83	15A Electronic throttle control actuator, ECM, EVAP canister purge valve, MAF sensor, ignition coils, main relay, VVT solenoids, high-pressure fuel pump, fuel injectors, engine compartment fuse block, air-fuel ratio (A/F) sensor, fuel heater, water-in-fuel sensor, coolant bypass valve
84	10A Engine Control Module (ECM), variable intake manifold solenoid, intake and exhaust VVT control valves
85	15A Air-fuel ratio (A/F) sensor, heated oxygen sensor (HO2S), turbocharger wastegate control valve, ECM, glow plug control unit
86	15A Fuel injectors, ignition coils, fuse box
87	15A A/C compressor clutch relay
88	Not used
89	Not used
90	30A Front wiper relay, front wiper motor
91	20A Fuel pump relay
92	Not used
93	10A ECM, Transmission Control Module (TCM), transmission range switch, under-hood fuse block, neutral position switch, primary speed sensor, secondary speed sensor, vehicle speed sensor, reverse/neutral switch
94	Not used
95	5A Electric Steering Column Lock (ESCL)
96	10A Stop-Start system restart relay
97	10A Right/left front combination headlamps, A/C compressor, transmission range switch, under-hood fuse block, neutral position switch, reverse lamp switch

Photograph of Secondary Fuse Box

Secondary Fuse Box Diagram

Headlamp Fuse Blocks

These blocks are located beneath the left headlamp assembly, behind the front bumper.

Block 1 – Location photo

Block 1 – Diagram

Block 2 – Location photo

Block 2 – Diagram

Battery Fusible Link Terminal Block

Mounted directly on the positive (+) terminal of the battery.
