Fuses and relays Nissan Tiida (C11/C12), 2004 - 2014

The Nissan Tiida is a C-segment compact car. The first-generation C11 model was produced from 2004 to 2010. The second-generation C12 was produced from 2011 to 2014, followed by the third-generation C13 starting in 2015. This article provides detailed information on the fuse and relay boxes in the Nissan Tiida (chassis codes C11 and C12; Nissan B and V platforms), including photographs, wiring diagrams, and component assignment lists, with specific emphasis on the fuse responsible for the cigarette lighter.

Verify fuse assignments against the diagram on the back of the protective cover.

In the passenger compartment


The passenger compartment fuse box is located inside the dashboard behind the access cover on the driver’s side.

Type 1


Fuse box diagram.

Circuit Protected / Description
1 10A Supplemental Restraint System (SRS airbag)
2 10A Auxiliary interior electrical accessories
3 10A Instrument cluster
4 15A Windshield washer pump motor
5 10A Heated door mirrors
6 10A Power mirrors, audio head unit
7 10A Brake lamps
8 10A Interior lamps
9 10A Body Control Module (BCM)
10 Spare
11 10A Right parking lamp, right tail lamp
12 10A Left parking lamp, left tail lamp
13 10A Instrument cluster
14 10A Auxiliary interior electrical accessories
15 15A Engine cooling fan motor
16 10A HVAC control system
17 15A Engine cooling fan motor
18 Spare
19 15A Auxiliary power socket (cigarette lighter)
20 Spare
R1 Blower motor relay
R2 Auxiliary power relay
R3 Unspecified relay
R4 Heated door mirror relay
R5 NATS immobilizer relay

Type 2


Fuse box diagram.

Description
1 10A Audio system, power mirror motors, NATS immobilizer (Intelligent Key)
2 10A Heated rear window and door mirrors
3 15A Front and rear windshield washer motor
4 10A Instrument cluster
5 10A Vehicle electronics
6 10A SRS airbag system module
7 10A Vehicle electronics
8 Spare
9 10A Interior and luggage compartment lamps
10 Spare
11 Spare
12 10A Brake lamps
13 10A Intelligent Key passive entry system
14 10A Vehicle electronics
15 15A Front power socket (cigarette lighter)
16 10A Heated front seats
17 15A Auxiliary power sockets (center console, luggage compartment)
18 15A HVAC blower motor
19 10A Air conditioning control system
20 15A HVAC blower motor

In the engine compartment

In the engine compartment adjacent to the battery, there are two main fuse and relay boxes, one auxiliary relay box, and a high-current fusible link block mounted on the positive battery terminal.

Primary fuse box

Type 1

Fuse box diagram.

Description
1 20A Rear window defogger
2 Spare
3 20A Engine Control Module (ECM)
4 Spare
5 30A Windshield wiper motor
6 Spare
7 10A A/C compressor magnetic clutch
8 10A License plate lamps
9 15A Front fog lamps (if equipped)
10 15A Left low-beam headlamp
11 15A Right low-beam headlamp
12 10A Right high-beam headlamp
13 10A Left high-beam headlamp
14 Spare
15 Spare
16 10A Heated oxygen sensors (HO2S)
17 10A Fuel injection system
18 Spare
19 15A Fuel pump module
20 10A Transmission Control Module (TCM)
21 10A ABS control module
22 10A Reverse lamp switch
23 Spare
24 15A Auxiliary equipment
R1 Rear window defogger relay
R2 Cooling fan relay No. 1
R3 Cooling fan relay No. 2
R4 Ignition relay

Type 2


Fuse box diagram.

Circuit Protected / Description
43 10A Right high-beam headlamp
44 10A Left high-beam headlamp
45 10A Air conditioning system, audio illumination, right side marker/tail lamps, headlight aiming motors
46 10A Parking lamps, seat heater switch illumination, door courtesy lamps
48 20A Windshield wiper motor
49 15A Left low-beam headlamp
50 15A Right low-beam headlamp
51 10A A/C compressor magnetic clutch
55 15A Rear window defogger
56 15A Rear window defogger
57 15A Fuel pump
58 10A Transmission Control Module (TCM)
59 10A ABS control module
60 10A Auxiliary electrical accessories
61 20A IPDM E/R B+ terminal, electronic throttle control motor and relay
62 20A IPDM E/R B+ terminal, ECM power supply (BATT/PW), ignition coils, CKP sensor, CMP sensor, EVAP canister purge valve, IVTC valve
63 10A Heated oxygen sensors (HO2S)
64 10A Fuel injectors, engine management system
65 20A Front fog lamps
R1 Rear window defogger relay
R2 ECM main relay
R3 Low-beam headlamp relay
R4 High-beam headlamp relay
R5 Starter relay
R6 Cooling fan relay No. 2
R7 Cooling fan relay No. 1
R8 Cooling fan relay No. 3
R9 Ignition relay

Auxiliary fuse box


Fuse box diagram.

1 10A NATS immobilizer
2 10A Heated seats
3 10A Alternator / Charging system
4 10A Horn / Warning chime
5 60A / 30A / 30A Electric Power Steering (EPS) control module, headlight washer motor, ABS module
6 50A Power window system
7 Spare
8 15A Diesel fuel injection system
9 10A Electronic throttle control actuator
10 15A Audio head unit
11 40A / 40A / 40A ABS control module, Body Control Module (BCM), ignition system
12 Spare
R1 Horn relay

Auxiliary relay box


Located on the right side of the engine compartment. Depending on vehicle equipment options, this box may contain up to two relays (e.g., windshield wiper speed relay and daytime running lamp [DRL] relay) or remain empty.

Fusible link block (battery terminal)

  1. 120A Electric Power Steering (EPS) control module, headlight washer motor, ABS system
  2. 60A Engine Control Module (ECM), electronic throttle control relay, power window relay
  3. 80A Low- and high-beam headlamps
  4. 80A NATS immobilizer, heated seats, alternator, horn
  5. 100A ABS control module, Body Control Module (BCM), ignition system, EPS control module, headlight washer motor
