Terrano is a crossover developed at Renault's technical center, and since 2013 produced under the Nissan brand as a rebranding product of the first-generation Duster model. Intended exclusively for the Russian and Indian markets. In this article, we will take a detailed look at the fuse diagrams for the Nissan Terrano (third generation / D10): 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022 model years.
Fuse f33 (type 1) or f38 (type 2) in the passenger compartment unit is responsible for protecting the cigarette lighter.
In the engine compartment
The fuse box is located on the left side of the engine compartment. To gain access, you need to remove the protective cover.
Type 1
Access example.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| Er1 | Horn relay | 20 |
| Er2 | Alarm Horn Relay | 20 |
| Er3 | Starter relay 1 | 35 |
| Er4 | Engine control system main relay | 35 |
| Er5 | A/C compressor clutch relay | 20 |
| Er6 | Terrano 3 fuel pump relay | 20 |
| Er7 | Heated windshield relay 2 | 35 |
| Cooling fan relay (without A/C) | ||
| Er8 | Heated windshield relay 1 | 35 |
| Er9 | Starter relay 2 | 20 |
| Ef1 | Fog lights | 10 |
| Ef2 | Electrical control unit | 7.5 |
| Ef3 | Rear window defroster, exterior mirror defoggers | 30 |
| Ef4 | ESC Stability Control Unit | 25 |
| Ef5 | Protection of fuses F11, F24-F27, F34, F39, F41 in the passenger compartment | 60 |
| Ef6 | Ignition switch (lock), protection of fuses F28, F31, F38, F43, F46, F47 in the cabin block | 60 |
| Ef7 | ESC Stability Control Unit | 50 |
| Ef8 | 12V socket in trunk | 80 |
| Ef9 | Not used | 20 |
| Ef10 | Heated windshield 1 | 40 |
| Ef11 | Heated windshield 2 | 40 |
| Ef12 | Starter | 30 |
| Ef13 | Not used | 15 |
| Ef14 | Electronic engine management system | 25 |
| Ef15 | A/C compressor clutch relay, A/C compressor clutch | 15 |
| Ef16 | Electric cooling fan | 50 |
| Ef17 | Automatic transmission control unit | 40 |
| Ef18 | Electric power steering pump | -80 |
| Ef21 | Not used | — |
| Ef22 | Not used | — |
| Ef23 | Oxygen concentration sensors, canister purge valve, camshaft position sensor, phase change valve | 15 |
| Ef24 | Electronic engine control unit, cooling fan control unit, ignition coils, fuel injectors, fuel pump | — |
| Ef25 | Gasoline pump | — |
Type 2
Block diagram.
| No. | Decryption | Amps |
| F1 | Spare | - |
| F2 | Spare | - |
| F3 | Fuel pump and ignition coils; Main relay - engine management system | 25 |
| F4 | Air conditioning compressor electromagnetic clutch circuit | 15 |
| F5 | Power Circuits: Cooling Fan Low Speed Relay K3 | 40 |
| F6 | fuses F9, F10, F28, F29, F30, F31, F32, F36 of distribution box 1 in the passenger compartment | 60 |
| F7 | fuses F13, F14, F15, F16, F17, F18, F19, F20, F24, F26, F27, F37, F38, F39 distribution box in the cabin | 60 |
| F8 | fuses F1, F2, F3, F4, F5, F11, F12 block in the cabin | 60 |
| F9 | Circuits under voltage in position S and A of the ignition key | 25 |
| F10 | Power circuits of the interior electric heater relay | 80 |
| F11 | ABS control unit circuits | 50 |
| F12 | - | 25 |
| K1 | Cooling fan motor | |
| K2 | A/C Compressor Clutch | |
| K3 | Cooling fan motor | |
| K4 | Fuel pump and ignition coil relay | |
| K5 | Oxygen concentration sensors (heating circuit), fuel injectors, canister purge valve, relay coils K1, K2, K3, engine control ECU | |
| K6 | - | |
| K7 | Fog lamps | |
| K8 | Heater fan motor | |
In the passenger compartment
The fuse box is located at the end of the dashboard. To gain access, use a screwdriver to pry up the protective lining and remove it.
Type 1
Access example.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amps |
| Panel 260-1 (main) | ||
| F1 | Front door power window | 30 |
| F2 | Left high beam | 10 |
| F3 | High beam right headlight | 10 |
| F4 | Low beam left headlight | 10 |
| F5 | Low beam right headlight | 10 |
| F6 | Tail lights | 5 |
| F7 | Front marker lamps | 5 |
| F8 | Rear door power window | 30 |
| F9 | Rear fog light | 7.5 |
| F10 | Sound signal | 15 |
| F11 | Automatic door lock | 20 |
| F12 | ABS systems – ESC, brake light switch | 5 |
| F13 | Courtesy light, luggage compartment lighting, glove compartment lighting | 10 |
| F14 | Not used | - |
| F15 | Windshield wiper | 15 |
| F16 | Multimedia system | 15 |
| F17 | Daylight lamps | 7.5 |
| F18 | Stop signal | 7 |
| F19 | Injection system, instrument panel, central electronic switching unit in the cabin | 5 |
| F20 | Airbag | 5 |
| F21 | All-wheel drive transmission with 4 driving wheels (4WD), reverse gear | 7.5 |
| F22 | Power steering | 5 |
| F23 | Cruise control/speed limiter, rear window relay, seat belt warning, park distance control, auxiliary interior heating relay | 5 |
| F24 | Central electronic switching unit for the cabin | 15 |
| F25 | 5 | |
| F26 | Turn signal lamps | 15 |
| F27 | Steering column switches | 20 |
| F28 | Horn | 15 |
| F29 | Steering column switches | 25 |
| F30 | Not used | - |
| F31 | Dashboard | 5 |
| F32 | Radio, interior air conditioning control panel, interior ventilation, rear connector for connecting electrical accessories | 7.5 |
| F33 | Terrano cigarette lighter fuse | 20 |
| F34 | Diagnostic connector and audio connector | 15 |
| F35 | Heated rear view mirror | 5 |
| F36 | Electric exterior mirrors | 5 |
| F37 | Central electronic switching unit, starter | 30 |
| F38 | Windshield wiper | 30 |
| F39 | Car interior ventilation | 40 |
| A | Electric climate control fan | - |
| B | Heated mirrors | - |
| Panel 260-2 (optional) | ||
| F1 | Not used | - |
| F2 | Electrical control unit, left headlight, right headlight | 25 |
| F3 | All-wheel drive transmission (4WD) | 5 |
| F4 | Additional electrical control unit | 15 |
| F5 | Rear accessory connector (female) | 15 |
| F6 | Electrical control unit | 5 |
| F7 | Not used | - |
| F8 | No data | 7.5 |
| F9 | Not used | - |
| F10 | Not used | - |
| Panel 703 | ||
| A | Additional power socket in luggage compartment | - |
| B | Not used | - |
| Panel 750 | ||
| A | Rear window locking | 40 |
Type 2
The second version of the interior unit.
| Diagram | ||
|---|---|---|
|
||
| No. | Purpose | Amps |
| F1 | Windshield cleaner; tailgate glass heating relay coils | 20 |
| F2 | Instrument cluster; winding of the fuel pump relay and ignition coils; power supply to the engine control system from the ignition switch | 5 |
| F3 | Brake lamps | 10 |
| F4 | Turn signal lamps; engine management system diagnostic connector (pin 1); immobilizer coils; switching block | 10 |
| F5 | Electromagnetic clutch of the rear gearbox | 5 |
| F6 | Spare | - |
| F7 | Spare | - |
| F8 | Spare | - |
| F9 | Low beam lamps of the left headlight | 10 |
| F10 | Low beam lamp, right headlight | 0 |
| F11 | Left headlight high beam lamp; high beam headlight indicator in the instrument cluster | 10 |
| F12 | Right headlight high beam lamp circuit | 10 |
| F13 | Rear door power windows | 30 |
| F14 | Front door power windows | 30 |
| F15 | ABS control module | 10 |
| F16 | Seat heating for driver and front passenger | 15 |
| F17 | Horn (sound signals) | 15 |
| F18 | Lamps of side lights of the left block headlight; left taillight lamps | 10 |
| F19 | Lamps for side lights of the right headlight; side lamps of the right rear lamp; license plate lamp; glove box lighting lamps; Illumination of the instrument cluster and controls on the instrument panel, console and floor tunnel lining | 10 |
| F20 | Rear fog lamps | 7.5 |
| F21 | Heated exterior mirrors | 5 |
| F22 | Spare | - |
| F23 | Spare | - |
| F24 | Power steering | 5 |
| F26 | Airbag control unit | 5 |
| F27 | parking sensors; reversing lamps; Windshield and tailgate glass washer | 20 |
| F28 | Bulbs in the interior lamp; trunk lamps; backlight lamps for the head unit of sound reproduction | 15 |
| F29 | Intermittent operation of the windshield wiper; turn signal switch; hazard switch; central locking; buzzer; engine management system diagnostic connector | 15 |
| F30 | central locking | 20 |
| F31 | Fog lights | 15 |
| F32 | Tailgate glass heated relay | 30 |
| F33 | Spare | - |
| F34 | Electromagnetic clutch of the rear gearbox | 15 |
| F35 | Spare | - |
| F36 | heater fan relay | 30 |
| F37 | Exterior mirrors | 5 |
| F38 | Terrano cigarette lighter fuse; power supply to the audio head unit from the ignition switch | 15 |
| F39 | HVAC Motor Relay | 10 |
