The crossover made its debut at the 2013 Geneva Motor Show, built on the Peugeot 208 hatchback platform. Its design was previewed by the Peugeot HR1 concept car, a compact three-door vehicle. The production model shifted to a five-door layout and is available exclusively with front-wheel drive. Below is a detailed reference guide to the fuse box diagrams for the Peugeot 2008 (1st Generation; chassis code A94; PSA PF1 platform) across model years 2014, 2015, 2016, 2017, 2018, and 2019.
Below are the locations and photographs of the power distribution boxes. Fuses for critical components such as the "Cigarette Lighter" and "Fuel Pump" are highlighted in bold.
Passenger Compartment
The interior features two fuse boxes designed to protect the vehicle’s electrical circuits.
Main Fuse Box
Located on the driver’s side at the lower section of the dashboard, behind the plastic trim panel. The illustration above shows how to gain access.
General view of the Peugeot 2008 passenger compartment fuse box.
| Diagram | ||
|---|---|---|
 |
||
| No. | Circuit / Component | Rating (A) |
| F2 | Power exterior mirrors, headlamps, diagnostic connector (OBD2). | 5 |
| F9 | Anti-theft alarm system. | 5 |
| F10 | Telematics control unit, trailer wiring harness ECU. | 5 |
| F11 | Auto-dimming interior rearview mirror, optional mirror heating. | 5 |
| F13 | Audio amplifier, parking assist module. | 5 |
| F16 |
|
15 |
| F17 | OEM audio system, aftermarket head unit. | 15 |
| F18 | Touchscreen display unit. | 20 |
| F23 | Glove compartment light, vanity mirror illumination, interior dome lights. | 5 |
| F26 | Horn. | 15 |
| F27 | Windshield washer pump. | 15 |
| F28 | Ignition switch and steering column lock module. | 5 |
| F29 | Air conditioning compressor clutch. | 15 |
| F30 | Rear window wiper motor. | 15 |
Auxiliary Fuse Box
Located behind the glove compartment panel.
| Diagram | ||
|---|---|---|
 |
||
| No. | Circuit / Component | Rating (A) |
| F01 | Heated rear window (defrost element). | 40 |
| F02 | Heated exterior mirrors. | 10 |
| F03 | Front power windows. | 30 |
| F04 | Unassigned | - |
| F05 | Rear power windows. | 30 |
| F06 | Power folding exterior mirrors. | 10 |
| F07 | 10 | |
| F08 | Unassigned | - |
| F09 | Heated front seats. | 15 |
| F10 | Audio amplifier. | 20 |
| F11 | Unassigned | - |
| F12 | Unassigned | - |
Engine Compartment
The under-hood fuse box is situated adjacent to the 12 V battery, beneath a protective cover.
Access procedure.
| Diagram | ||
|---|---|---|
 |
||
| No. | Circuit / Component | Rating (A) |
| F16 | Front fog lamps. | 15 |
| F18 | Right high-beam headlamp. | 10 |
| F19 | Left high-beam headlamp. | 10 |
| F25 | Headlamp washer relay (aftermarket/optional). | 30 |
| F29 | Windshield wiper motor. | 40 |
| F30 | Glow plug control module (diesel variants). | 80 |
