The compact Peugeot 4007 crossover has been produced since 2007. Developed alongside the Citroën C-Crosser, it shares its platform with the second-generation Mitsubishi Outlander. This article provides detailed fuse box diagrams for the Peugeot 4007 (1st generation; chassis code GP; Mitsubishi GS platform) covering model years 2007, 2008, 2009, 2010, 2011, 2012, 2013, and 2014.
Below you will find the locations and diagram illustrations for the power distribution boxes. Fuses for critical components such as the “Cigarette Lighter” and “Fuel Pump” are highlighted in bold.
In the engine compartment
There are three distribution units located in the engine bay:
- Main fuse box (to the right of the battery);
- Auxiliary relay box next to the main fuse box (equipped depending on vehicle specification);
- Battery-mounted distribution board (fusible link block).
Main fuse box
Photo: Typical main fuse box configuration.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating (A) |
| 1 | I/O module / Gateway ECU | 30 |
| 2 | Engine cooling fan motor | 40 |
| 3 | A/C condenser fan motor | 30 |
| 4 | ABS / ESP system module | 30 |
| 5 | 40 | |
| 6 | Spare | - |
| 7 | Starter motor relay | 30 |
| 8 | Front fog lamps | 15 |
| 9 | Engine management ECU | 7.5 |
| 10 | Automatic transmission control unit (TCM) | 20 |
| 11 | Horn | 10 |
| 12 | Alternator / charging system | 7.5 |
| 13 | Headlamp washers | 20 |
| 14 | Air conditioning compressor clutch | 10 |
| 15 | Electronic throttle body actuator | 15 |
| 16 | Anti-theft alarm siren / buzzer | 20 |
| 17 | Windshield wiper de-icer | 15 |
| 18 | Spare | - |
| 19 | Power tailgate actuator | 30 |
| 20 | Daytime running lights (DRL) | 10 |
| 21 | High beam headlamp (Left) | 10 |
| 22 | High beam headlamp (Right) | 10 |
| 23 | Audio system amplifier | 30 |
| 24 | Diesel engine management components | 30 |
| 25 | Low beam headlamp, left (HID / Xenon) | 20 |
| 26 | Low beam headlamp, right (HID / Xenon) | 20 |
| 27 | Low beam headlamp, left (Halogen) | 10 |
| 28 | Low beam headlamp, right (Halogen) | 10 |
| 29 | Engine control supply circuit | 10 |
| 30 | Ignition coils | 10 |
| 31 | Engine management power supply | 20 |
| 32 | Peugeot 4007 fuel pump fuse | 15 |
| Relay Assignments | ||
| R1 | Glow plug control module (Diesel) | |
| R2 | Engine cooling fan | |
| R3 | Blower motor / Climate control | |
| R4 | Engine management system (Main relay) | |
| R5 | Stability control system (ESP/ABS) | |
| R6 | A/C condenser fan | |
| R7 | Engine management system | |
| R8 | Low beam headlamps | |
| R9 | Engine management system | |
| R10 | Windshield wiper de-icer | |
| R11 | Daytime running lights (DRL) | |
| R12 | Engine management system | |
| R13 | Hazard warning flashers | |
| R14 | Automatic transmission (TCM) | |
| R15 | Headlamp washer pump | |
| R16 | High beam headlamps | |
| R17 | Front fog lamps | |
| R18 | Horn relay | |
| R19 | A/C clutch relay | |
Auxiliary relay box
The auxiliary relay box is positioned adjacent to the main fuse block, near the battery negative (-) terminal.
|
|
| R1 | Radiator cooling fan (Low speed) |
| R2 | A/C condenser fan |
| R3 | Radiator cooling fan (High speed) |
In the passenger compartment
Located behind the access cover on the driver’s side lower instrument panel.
General view of the Peugeot 4007 passenger compartment fuse box.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Designation | Rating (A) |
| 1 | Climate control / Heater blower motor | 30 |
| 2 | Brake lights (Stop lamps) | 15 |
| 3 | Rear fog lamp | 10 |
| 4 | Windshield wipers | 30 |
| 5 | Spare | - |
| 6 | Auxiliary equipment power circuit | 10 |
| 7 | Central locking system | 20 |
| 8 | Audio system / Infotainment head unit | 15 |
| 9 | Auxiliary equipment power circuit | 7.5 |
| 10 | Interior lighting / Dome lamps | 15 |
| 11 | Hazard warning lights | 15 |
| 12 | Rear window wiper | 15 |
| 13 | Instrument cluster | 7.5 |
| 14 | Spare | - |
| 15 |
|
15 |
| 16 | Ignition switch / Steering lock unit | 10 |
| 17 | Power sunroof | 20 |
| 18 | Spare | - |
| 19 | Power exterior mirrors | 10 |
| 20 | Four-wheel drive control unit (4WD / AWD) | 10 |
| 21 | Reversing lamps (Back-up lights) | 7.5 |
| 22 | Spare | - |
| 23 | Auxiliary 12V power outlet | 15 |
| 24 | Power windows | 30 |
| 25 | Heated rear window (Demister) | 30 |
| 26 | Heated door mirrors | 7.5 |
| 27 | Accessories power supply | 15 |
| 28 | Power seats | 25 / 20 |
| 29 | Heated front seats | 30 |
| Relay Assignments | ||
| R1 | Central door locking | |
| R2 | Blower motor / Climate control | |
| R3 | Heated seats | |
| R4 | Heated rear window | |
