Peugeot 605 is a business class car produced by a French company from 1989 to 1999, the last car of the manufacturer with an index ending in 05. Co-platform Citroën XM .
In our material, we will analyze in detail the fuse circuits of the 1st generation Peugeot 605 (6B body) 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998 and 1999 release. Here you can find the locations and photos of the mounting blocks. Separately, we note the fuse responsible for the cigarette lighter.
In the passenger compartment
Located at the bottom of the dashboard.
Fuse box general view.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | A |
| 1 | ABR system | 10 |
| 2 | Stop signals, interior lighting, cruise control, ABS, telephone. | 10 |
| 3 | Spare. | 5 |
| 4 | ABS control unit. | 10 |
| 5 | Interior temperature sensor. Light ‚rear-view mirrors, clock or on-board computer, reading lights, heater, coolant level sensor, remote control signal receiver, central locking, radiator fan relay, glass lifters. Sunroof. | 10 |
| 6 | Fog lights. | 5 |
| 7 | Spare. | 20 |
| 8 | 30 | |
| 9 | Window lifters. Glass cleaner. | 30 |
| 10 | plate lights, front parking lights, warning lights, switch lights. | 10 |
| 11 | Heated lambda probe. | 15 |
| 13 | Light alarm. Telephone. | 15 |
| 14 | Left tailgate, backlight control, radio receiver, instrument panel lighting, heater switches, sunroof switch. | 5 |
| 15 | Fuel pump fuse | 15 |
| 17 | Seat heater. | 30 |
| 18 | Right tailgate, clock or on-board computer, parking light warning light. cigarette lighter lighting, interior lighting switches. | 5 |
| 19 | The control unit for adjusting the stiffness of the shock absorbers, the cruise control control unit. | 15 |
| 21 | Front door windows, sunroof. | 30 |
| 22 | Headlight washers. | 20 |
| 23 | Reversing lights, fuel filter condensate level sensor, power steering, thermal switch for fan and radiator blower. | 15 |
| 25 | Rear side door window switches. | 30 |
| 26 | Peugeot 605 cigarette lighter fuse. Sound signal. |
20 |
| 27 | Clock, on-board computer, interior lighting, trunk lighting, fuel supply indication, warning lights on the doors. | 10 |
| 28 | No | |
| 29 | Rear side door window switches on the driver's panel. | 30 |
| 30 | Front left seat position adjuster. | 30 |
| 32 | Radio | 20 |
| 33 | Heated rear window and exterior mirrors. | 30 |
| 34 | Central locking, locking, burglar alarm. | 30 |
| 35 | Front right seat adjuster. | 30 |
| 36 | Air conditioner relay. | 30 |
In the engine compartment
Located near the battery.
Access example.
| A | Fuse assignment |
| 30 | fans (2 pcs.) reserve (1 pc.) |
| 50 | ABS system; |
| shunt | anti-blocking system of wheels; |
| 20 | compressor alarm; |
