This material discusses in detail the fuse diagrams of the Renault Arkana (first generation / platform B0): 2018, 2019, 2020, 2021, 2022, 2023, 2024 of release.
Fuse number 30 in the passenger compartment is responsible for protecting the electrical circuit of the cigarette lighter.
In the engine compartment
On the positive terminal of the battery is a block of power fuses (#1). The main underhood fuse box (#2) is located next to the battery.
Power fuse links
Access example.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amp |
| 1 | Fuse protection #ef1-ef7 in the engine compartment block (#2) | 200 |
| 2 | Generator, starter | 300 |
| 3 | electric power steering | 80 |
| 4 | Fuse box in the cabin | 80 |
| 5 | ABS and trajectory stabilization systems | 50 |
| 6 | Fuse box in the cabin | 80 |
| 7 | Cabin central electronic switching unit | 7.5 |
Fuse box
Access example.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amp |
| Er1 | Starter | |
| Er1 | Switching on the reversing lamp | |
| Er2 | burglar alarm siren | |
| Er3 | Starter | |
| Er3 | Electric cooling fan | |
| Er3 | Switching on the reversing lamp | |
| Er4 | Main relay of the engine management system | |
| Er5 | A/C Compressor Magnetic Clutch Relay | |
| Er6 | Renault Arkana fuel pump relay | |
| Ef1 | Heated washer nozzles | 5 |
| Electrical control unit | 7.5 | |
| Ef2 | Not involved | - |
| Ef3 | Stability Control Unit, ABS/ESP | 25/30 |
| Ef4 | Rear window defroster, exterior mirror defrosters, cabin fuses 38 and 47 | 40 |
| Ef5 | Fuse circuit protection 5 / 23 / 24 / 25 / 26 / 27 / 42 / 44 in the passenger compartment | 20/70 |
| Ef6 | Cabin Fuse and Relay Box, Heater Relay | 80 |
| Ef7 |
|
50 |
| Ef8 | Not involved | - |
| Ef9 | Additional heater | 80 |
| Ef10 | Heated windshield, right side | 40 |
| Ef11 | Heated windshield, left side | 40 |
| Ef12 | Starter | 30 |
| Ef13 | Automatic transmission control unit | 15 |
| Ef14 | ECU and engine circuit protection, fuse protection 5 in the cabin, engine injectors, fuel gauge, fuel pump fuse, ignition coils | 25 |
| Ef15 | A/C Compressor Clutch | 15 |
| Ef16 | Radiator cooling fan | 50 |
| Ef17 | Automatic transmission fluid cooling electric fan | 40 |
| Ef18 | Power steering pump | 80 |
| Ef19 | Not involved | - |
| Ef20 | Not involved | - |
| Ef21 | Not involved | - |
| Ef22 | Not involved | - |
| Ef23 | Engine control system, fan control unit, air conditioning compressor relay control. | 15 |
| Ef24 | Not involved | - |
| Ef25 | Not involved | - |
| Ef26 | Not involved | - |
| D | AC compressor clutch diode | - |
In the passenger compartment
The fuse box is located behind a protective cover on the driver's side.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | Amp |
| A | power window switch relay | 70 |
| A | time relay "+" battery | 20 |
| B | horn relay | 20 |
| A | heater fan relay | 40 |
| A | rear window heating relay | 40 |
| 1 | Front door power windows | 30 |
| 2 | Not involved | - |
| 3 | Not involved | - |
| 4 | Not involved | - |
| 5 | Not involved | - |
| 6 | Not involved | - |
| 7 | Subwoofer | 25 |
| 8 | Rear door windows. | 30 |
| 9 | Steering wheel heating | 10 |
| 10 | Not involved | - |
| 11 | Central locking of all 4 doors | 20 |
| 12 | Clutch pedal position sensor, immobilizer receiving ring - in a modification with a key. Fuse for the ABS control unit and the stabilization system of the trajectory of the movement | 5 |
| 13 | Interior lamps, climate control system | 10 |
| 14 | Rain and light sensor, child safety relay control - rear power window lock | 5 |
| 15 | interior central electronic switching unit, windshield wiper and washer | 15 |
| 16 | Hands Free ECU, CAN Master Gateway, Surround Cameras, Heated Seats | 25 |
| 17 | Not involved | - |
| 18 | Only for cars with a key - brake light | 7.5 |
| 19 | injection computer | 5 |
| 20 | SRS system | 5 |
| 21 | AWD system, reversing lamps | 7.5 |
| 22 | Power steering | 5 |
| 23 | Tubular electric heater of the interior heater, ECU of standard parking sensors, indicator of not fastened seat belt, heated rear window, headlight range control, heated windshield. | 5 |
| 24 | Fuse protection #12, 13, 14, 36 | 15 |
| 25 | Power consumption ECU, telemetry system, main CAN network gateway | 5 |
| 26 | Rear lights, automatic transmission selector, electric exterior mirrors | 15 |
| 27 | Power supply for the towbar wiring matching unit | 20 |
| 28 | Fuse circuits #32-33 | 20 |
| 29 | Not involved | - |
| 30 | Headlights, Cruise Control, Rear Fog Lamp, Rear Power Window, 4WD Mode Switch, License Plate Light, Blind Spot Monitor, Climate Control Panel, Cigarette Lighter, Exterior Mirror Switch Power | 25 |
| 31 | instrument panel | 5 |
| 32 | heater fan | 7.5 |
| 33 | Renault Arkana Cigarette Lighter Socket Fuse | 15 |
| 34 | Diagnostic connector, audio system | 25 |
| 35 | Power mirrors | 5 |
| 36 | Power mirrors | 5 |
| 37 | For cars with key - starter | 30 |
| 38 | Front glass cleaner | 30 |
| 39 | For cars with a Start-Stop button - control of the relay of electricity consumers. | 40 |
| 40 | Horn relay, hands-free access system control unit | 15 |
| 41 | Driver's window closer | 30 |
| 42 | All-wheel drive system | 5 |
| 43 | Not involved | - |
| 44 | Not involved | - |
| 45 | Not involved | - |
| 46 | Relay after ignition switch, power consumption computer, fuse circuits 19-23 | 20 |
| 47 | For cars without a key - brake light | 7.5 |
| 48 | Heated seats | 15 |
| 49 | Front fog lights and high/low beam headlights | 25 |
