In this article, we will take a detailed look at the fuse diagrams for the Renault Megan car (fourth generation: K9A station wagon / L9A sedan / B9A hatchback 5 doors): 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024 of release.
Fuse number 30 in the passenger compartment is responsible for protecting the electrical circuit of the cigarette lighter.
In the engine compartment
There are two distribution boxes here, which are responsible for protecting the vehicle's electrical circuits.
Fuse box
Fuse box located on the left side of the engine compartment. To access it is necessary to remove the protective lining. It consists of two sections: upper and lower.
The photo shows an example.
| Diagram | ||
|---|---|---|
| No. | Description | Amps |
| Upper section | ||
|
||
| 1 |
|
10 |
| 2 | Electronic control unit and relay of the fuel injection system (preheating) | 15 |
| 3 | Electronic control unit for the injection system | 15 |
| 4 | Electronic control unit for the fuel injection system (120) and engine circuits | 10 |
| 5 | engine management | 15 |
| 6 | auxiliary heating relay 1 and 2 (1067-1068) on the board (1067), automatic parking brake and cruise control/speed limiter control (2519), shift mode switch (129), gear lever position indicator (1129), electronic unit parking system control unit (1222), interior rearview mirror (1340), seat belt warning unit (1601), front camera control unit (2236), automatic parking brake control unit (1217), limiter switch and cruise control unit (1081) , rear window heating relay control (235) in the passenger compartment fuse and relay box (260), left and right headlight corrector motors (537-538) | 15 |
| 7 | air conditioning compressor clutch (171) | 15 |
| 8 | ABS and/or ESP electronic control unit (1094) | 30 |
| 9 | A/C refrigerant pump (2084) | 15 |
| 10 | windshield wiper motor (212) | 30 |
| 11 | Fuel level sensor, fuel temperature sensor, fuel pump fuse | 20 |
| 12 | Starter | 30 |
| 13 | Electronic transmission control unit | 10 |
| 14 | Electric Power Steering (1232), Stop Lamp Switch (160), 4WD ECM (1663) | 5 |
| 15 | Injection ECU (120), remote self-adjusting governor control unit (2037) | 5 |
| 16 | electric steering column lock (1088), steering wheel angle sensor (583), airbag/pretensioner control module (756) | 10 |
| 17 | neutral position sensor for manual transmission / reverse light (1109), fuel heater relay control (450), reverse light relay | 10 |
| Bottom section | ||
|
||
| Panel 777 | ||
| F1 | Not involved | - |
| F2 | Not involved | - |
| F3 | Not involved | - |
| F4 | headlight washer pump relay | 20 |
| F5 | windshield heating | 80 |
| F6 | Four-wheel drive electronic control unit (1663) | 40 |
| F7 | fuse supply circuits (F57 - F58 - F59 - F60) in the cabin unit | 70 |
| A | headlight washer relay | - |
| Panel 753 | ||
| A | headlight washer relay | - |
| B | Not involved | - |
| Panel 597 | ||
| F1 |
|
30 |
| F2 | automatic transmission control unit | 15 |
| F3 |
|
30 |
| F4 | protection and switching unit (1337) | 140 |
| F5 |
|
70 |
| F6 | Electronic control unit automatic transmission (119) | 50 |
| F7 | engine cooling fan (188) | 60 |
| F8 | heating control circuits (1550) | 70 |
| F9 | auxiliary heater interface unit (1550) | 70 |
| A | Reverse Lamp Relay | - |
| 450 | Fuel heating relay | - |
| Panel 597-3 | ||
| A | Remote Engine Start Relay (2619) | - |
| B | fuel pump relay (2523) - diesel | - |
| D | Engine injector relay | - |
| E | Engine injector relay | - |
Power fuse links
This unit consists of high power fuses. It is located near the positive terminal of the battery.
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | Purpose | Amps |
| F1 | (1232) Electric power steering | 60 |
| F2 | (1113) Additional interior heating | 100 |
| F3 | Fuse and relay supply circuits | 80 |
| F4 | (1094) ABS-ESP systems control unit | 40 |
| F5 | Fuse and relay supply circuits | 100 |
| F6 | 100 | |
| F7 | Starter, generator | 300 |
In the passenger compartment
The fuse box is located at the bottom of the dashboard behind a protective cover.
General view of the distribution box.
| Diagram | ||
|---|---|---|
|
||
| No. | Amps | Description |
| 1 | - | Not involved |
| 2 | 10 | sockets for multimedia equipment (2468) in right-hand drive version |
| 3 | 15 | fuel filler flap lock motor (844), driver and passenger door central locking (140-141) |
| 4 | 15 | front direction indicators (255-256), rear lights (172-173), trailer connector switching module (1971), electrically adjustable exterior mirrors (2230-2231) |
| 5 | 15 | rear passenger door central locking (138-139), upper brake light (639), tailgate lock (1322) |
| 6 | - | Not involved |
| 7 | - | Not involved |
| 8 | - | Not involved |
| 9 | 15 | rear fog lights (174-175), rear window wiper motor (211) |
| 10 | 30 | parking brake control module (1217) |
| 11 | - | Not involved |
| 12 | 15 | variable damping system (543) |
| 13 | power circuits for fuses 3, 4, 5 and 6 in the passenger compartment (260) | |
| 14 | - | Not involved |
| 15 | - | Not involved |
| 16 | 10 | Dashboard (247) |
| 17 | 20 | horn relay (229) |
| 18 | 10 | diagnostic connector (225) and alarm (1838) |
| 19 | 20 | trailer connector (1971) |
| 20 | 10 | A Cabin Central Electronic Switching Unit (BCM) |
| 21 | 20 | audio system (261), telemetry control unit (2152) |
| 22 | 10 | automatic parking brake and cruise control/speed limiter controls (2519), CD changer (1272), multifunction display (2402), multimedia outlets (1877) |
| 23 | 0 | audio system amplifier (1917) |
| 24 | 30 | parking brake computer (1217) |
| 25 | 10 | rear lights (172-173), trailer connector (1971) |
| 26 | - | Not involved |
| 27 | 5 | electric outside rear-view mirrors (2230-2231) |
| 28 | - | Not involved |
| 29 | - | Not involved |
| 30 | 15 | Cigarette lighter fuse Renault Megane 4 (101) or sockets for additional equipment (506) |
| 31 | 15 | cigarette lighter sockets in luggage compartment (1384) |
| 32 | 10 | double-acting windshield and rear washer pump (677) |
| 33 | Output: fuse supply circuits (F2) in passenger compartment fuse and relay box (260) RHD version | |
| 34 | 40 | interior electric fan 1 (1156) |
| 35 | 40 | Heated rear window (235) |
| 36 | 40 | backdoor |
| 37 | - | Not involved |
| 38 | 10 / 15 | passenger side stowage compartment release motor (2518) 10A, fuel filler flap lock motor (844) 15A |
| 39 | 10 | air conditioner control unit (419), opening element horn unit (wac) (1920) |
| 40 | 7.5 | clutch position sensor (1057) in modification with manual transmission - display on the windshield (2400) in modification with a display on the windshield, version 1 - receiving ring (1618) in modification with a system for locking and unlocking doors in the hands-free mode on 433 MHz |
| 41 | 7.5 | interior lighting lamps |
| 42 | 5 | Power door mirrors (2230-2231) via multiplex door matrix control (1667), front passenger door light (1752), door light |
| 43 | 5 | ABS and/or ESP ECU (1094), brake light switch (160) |
| 44 | - | Not involved |
| 45 | 7.5 | rain and sun sensor (1415), interior air temperature sensor (1872), interior lamps (328-329), passenger and driver sun visor lamps (541), rear crossmember interior lamp (300) |
| 46 | 25 | driver's door electric window motor (203) |
| 47 | 25 | passenger door power window motor (204) |
| 48 | 30 | sunroof (304) |
| 49 | 25 | rear left electric window motor (202) |
| 50 | 25 | rear right power window motor (201) |
| 51 | 25 | front right seat memory computer (2576) |
| 52 | 15 | rear seat fold switch |
| 53 | 25 | Front Left Seat Position Memory ECU (2567): Front Left Seat Lumbar Adjustment (2564), Front Left Seat 2 Lumbar Support Adjustment (2565) |
| 54 | 40 | windshield wiper motor |
| 55 | 40 | windshield wiper motor |
| 56 | Output: fuse protection 38 in cabin unit (260) | |
| 57 | 30 | rear cabin fan |
| 58 | 15 | heated rear left and right seat controls (2120-2121), rear left and right seat cushion heating elements (2423-2424) |
| 59 | 20 | front left and right seat position memory control unit (2567 / 2576), front seat heating (987-988), front left and right seat heating control unit (985-986) |
| 60 | 7.5 | heated steering wheel control (2483), cruise control and airbag switch (689) |
| 61 | output: protection relay No. 2 after the ignition switch (ap2) (752) in the cabin unit (260-4) | |
| 62 | Output: fuse protection (F16-F17-F18-F19-F35) in cabin unit (260-1) | |
| A | 70 | RELAY 1 "+" BATTERY WITH POWER OFF DURING START (1760) |
| B | 70 | Time Delayed Battery + Relay Not Turned Off (NO POWER OFF DURING START) (1762) |
| C | - | Not involved |
| D | - | Not involved |
| F | 40 | Heated rear window (235) |
| G | 20 | Horn relay (229) |
| H | 20 | Steering wheel heating (2499) |
