Sleek exterior styling, an updated engine lineup, and improved interior materials—despite these upgrades, the third-generation Škoda Octavia remains a thoroughly practical family car. In this article, we provide detailed fuse box diagrams and locations for the Škoda Octavia (3rd generation; chassis code 5E; MQB platform) covering model years 2013, 2014, 2015, 2016, and the facelifted models from 2017, 2018, 2019, and 2020.
Below you will find the locations and photos of the power distribution boxes. Fuses responsible for the “Cigarette lighter” and “Fuel pump” are highlighted in bold.
In the Engine Compartment
The fuse box is located on the right side of the engine compartment behind a protective cover. To access the fuses, press both locking catches (1) simultaneously and pull the cover upward.
Fuse box cover removal.
2013–2016 Model Years
Fuse assignment and layout in the engine compartment fuse box.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | A |
| F1 | Equipment control module | 20 |
| Automatic transmission with Adaptive Cruise Control (ACC) | 40 | |
| F2 | ABS / ESC control module | 40 |
| F3 | Engine Control Module (ECM) – Petrol | 20 |
| Engine Control Module (ECM) – Diesel | 30 | |
| F4 | Engine electronics, low heat output relay, high heat output relay (diesel) | 5 |
| Engine electronics (petrol) | 10 | |
| F5 | Ignition OFF relay, engine electronics | 10 |
| F6 | Brake light switch | 5 |
| F7 | Coolant shut-off valve, coolant control valve (CJSA, CJSB, CHHB engines) | 5 |
| Engine electronics (CJZB, CJZA, CUPA, CLHB, CLHA, CRVC, CKFC engines) | 10 | |
| F8 | Oxygen sensor (Lambda probe), downstream oxygen sensor (CJZB, CJZA, CLHB, CLHA, CKFC, CUPA engines) | 10 |
| Oxygen sensor (Lambda probe), downstream oxygen sensor (CUPA, CJSA, CJSB, CHHB engines) | 15 | |
| F9 | Glow plug control module, crankcase ventilation heating element (diesel engines) | 5 |
| Engine electronics (CJSA, CJSB, SNNV engines) | 10 | |
| Ignition system (CJZB, CJZA, SIRA engines) | 20 | |
| F10 | Škoda Octavia A7 fuel pump fuse (petrol engines) | 15 |
| Fuel pump control module (diesel engines) | 20 | |
| F11 | Auxiliary air heater element | 40 |
| F12 | 40 | |
| F13 | Dual-clutch transmission mechatronic unit (0D9 transmission) | 15 |
| Dual-clutch transmission mechatronic unit (0CW transmission) | 30 | |
| F14 | Heated windshield relay | 30 |
| F15 | Horn | 20 |
| F16 | Ignition switch | 20 |
| F17 | Main relay, Engine Control Module (ECM), ABS control module | 7.5 |
| F18 | Data bus diagnostic interface (vehicles without auxiliary heating/Start-Stop), battery monitoring control module (vehicles with auxiliary heating/Start-Stop) | 5 |
| F19 | Windshield wiper motor control module | 30 |
| F20 | Anti-theft alarm siren | 10 |
| F21 | ABS / ESC control unit | 20 |
| F22 | Engine Control Module (ECM) | 5 |
| F23 | Starter motor | 30 |
| F24 | Auxiliary air heater element | 40 |
| F25 | Vacant | |
| F26 | Vacant | |
| F27 | Vacant | |
| F28 | Vacant | |
| F29 | Vacant | |
| F30 | Vacant | |
| F31 | Brake vacuum pump | 15 |
| F32 | Vacant | |
| F33 | Vacant | |
| F34 | Heated windshield relay 2 | 30 |
| F35 | Vacant | |
| F36 | Vacant | |
| F37 | Auxiliary heater control module | 20 |
| F38 | Vacant | |
| R1 | Starter relay 1 | |
| R2 | Starter relay 2 | |
| R3 | Horn relay | |
| R4 | High heat output relay | |
| R5 | Main relay | |
2017–2020 Model Years (Facelift)
Engine compartment fuse box layout for facelifted 2017–2020 models.
| Diagram | |
|---|---|
|
|
| No. | Protected Component / Circuit |
| 1 | ESC, ABS, Electronic Parking Brake |
| 2 | ESC, ABS |
| 3 | Engine management system |
| 4 | Radiator fan, oil temperature sensor, mass air flow meter, fuel pressure regulator, auxiliary electric heater, oil pressure regulator, EGR valve, glow plug preheating system, SCR control module (AdBlue®) |
| 5 | Ignition system, CNG relay coil, fuel injectors, fuel metering valve |
| 6 | Brake system pressure sensor |
| 7 | Coolant pump, radiator shutter blinds, oil pressure control valve, auxiliary heater |
| 8 | Crankcase ventilation heating element |
| 9 | Oxygen sensor (Lambda probe) |
| 10 | Ignition coils, exhaust flap valve |
| 11 | Fuel pump fuse, ignition system |
| 12 | Auxiliary electric heater element |
| 13 | |
| 14 | Heated windshield (left side) |
| 15 | Heated windshield (right side) |
| 16 | Horn |
| 17 | Ignition system, fuel pump, CNG relay |
| 18 | ABS, ESC, Engine Control Module (ECM), heated windshield relay |
| 19 | Data bus interface, battery monitoring control module |
| 20 | Windshield wipers |
| 21 | Anti-theft alarm system |
| 22 | Automatic transmission control module |
| 23 | Engine management system |
| 24 | Starter motor |
| 25 | Auxiliary electric heater |
| 26 | Vacant |
| 27 | Vacant |
| 28 | Vacant |
| 29 | Vacant |
| 30 | Vacant |
| 31 | Vacant |
| 32 | Brake vacuum pump |
| 33 | Vacant |
| 34 | Automatic transmission auxiliary oil pump |
| 35 | Front axle electronic differential lock (VAQ) |
| 36 | Vacant |
| 37 | Vacant |
| 38 | Auxiliary heater |
| 39 | Vacant |
In the Passenger Compartment
Left-hand drive (LHD) models: located behind the glove box on the driver side.
Right-hand drive (RHD) models: located behind the glove box on the passenger side.
Glove box removal for fuse access.
General overview of the passenger compartment fuse panel.
2013–2016 Model Years
Passenger compartment fuse box diagram and pinout.
|
||
| No. | Protected Component / Circuit | A |
| F1 | Vacant | - |
| F2 | Vacant | - |
| F3 | Vacant | - |
| F4 | Vacant | - |
| F5 | Data bus diagnostic interface | 5 |
| F6 |
|
5 |
| F7 | Heated rear window relay, HVAC control module, climate control unit, auxiliary heater receiver | 10 |
| F8 | 16-pin OBD2 diagnostic port, rain and light sensor, humidity sensor, headlight switch | 10 |
| F9 | All-Wheel Drive (AWD) control module | 15 |
| F10 | Infotainment / Multimedia system | 10 |
| F11 | Heated rear seat control module | 25 |
| F12 | Infotainment control module | 20 |
| F13 | Driver seat belt tensioner / switch | 25 |
| F14 | Fresh air blower / HVAC fan | 30 |
| F15 | Electronic steering column lock (ELV) | 10 |
| F16 | Telephone module | 7.5 |
| Cellular signal booster | 5 | |
| F17 | Instrument cluster | 5 |
| F18 | Vacant | |
| F19 | Keyless entry and ignition system (KESSY) control module | 7.5 |
| F20 | Steering column electronics control module | 5 |
| F21 | Vacant | |
| F22 | Tailgate / Trunk control module | 30 |
| F23 | Body Control Module (BCM) / Central electrical control unit | 40 |
| F24 | Panoramic sliding / tilt sunroof control module | 30 |
| F25 | Driver door control module, rear-left power window motor | 30 |
| F26 | Body Control Module (BCM) – heated seats | 25 |
| F27 | Digital sound package / Audio amplifier module | 30 |
| F28 | Trailer towing control module | 20 |
| F29 | Vacant | |
| F30 | Vacant | |
| F31 | Body Control Module (BCM) | 40 |
| F32 | Park distance control (Parktronic) / Park assist module | 7.5 |
| F33 | Front passenger airbag deactivation switch/indicator, Airbag Control Module | 5 |
| F34 | Headlight switch, reverse light switch, A/C refrigerant pressure sensor, rear seat heating unit, auto-dimming rear-view mirror, 12V-to-230V inverter, mobile phone preparation | 7.5 |
| F35 | OBD2 diagnostic connector, headlight levelling control unit and actuators, driver assistance front camera | 10 |
| F36 | Right headlight control module | 10 |
| F37 | Left headlight control module | 10 |
| F38 | Trailer towing control module | 20 |
| F39 | Front passenger door control module, rear-right power window motor | 30 |
| F40 | Cigarette lighter fuse (Škoda Octavia A7), 12 V power socket |
20 |
| F41 | Vacant | |
| F42 | Body Control Module (BCM) | 40 |
| F43 | 30 | |
| F44 | Trailer towing control module | 30 |
| F45 | Driver seat adjustment power circuit breaker | 30 |
| F46 | 230 V power socket inverter | 30 |
| F47 | Rear window wiper motor | 15 |
| F48 | Vacant | |
| F49 | Starter relays 1 & 2, clutch pedal position sensor | 5 |
| F50 | Vacant | |
| F51 | Front passenger seat belt tensioner module | 25 |
| F52 | Vacant | |
| F53 | Heated rear window | 30 |
| Rel4 | Terminal 15 power supply relay | |
| Rel5 | Heated rear window relay | |
| Rel6 | Load shedding relay | |
2017–2020 Model Years (Facelift)
Passenger compartment fuse box description for facelifted 2017–2020 models.
| Diagram | |
|---|---|
|
|
| No. | Protected Component / Circuit |
| 1 | Vacant |
| 2 | Vacant |
| 3 | Vacant |
| 4 | Heated steering wheel |
| 5 | Data bus interface |
| 6 | Interior motion / alarm sensor |
| 7 | Air conditioning, auxiliary heater receiver, automatic transmission selector lever, heated rear window relay, ignition key removal lock |
| 8 | Light switch, rain/light sensor, OBD2 diagnostic connector, ambient lighting, headlight control module |
| 9 | All-Wheel Drive (AWD) clutch |
| 10 | Infotainment screen display |
| 11 | Exterior lighting (left side) |
| 12 | Infotainment head unit |
| 13 | Driver seat belt pretensioner |
| 14 | Blower fan (HVAC) |
| 15 | Electronic steering column lock |
| 16 | Phonebox / Wireless charging pad |
| 17 | Instrument cluster, eCall (emergency call system) |
| 18 | Rearview camera |
| 19 | Keyless entry and start system (KESSY) |
| 20 | Steering wheel controls / Multifunction switches |
| 21 | Adaptive chassis control (DCC) |
| 22 | Trailer towing module |
| 23 | Panoramic sunroof |
| 24 | Exterior lighting (right side) |
| 25 | Central locking (driver door), power window (left), heated & power-folding exterior mirror (left) |
| 26 | Heated front seats |
| 27 | Interior lighting |
| 28 | Trailer towing module |
| 29 | SCR system (AdBlue®) |
| 30 | Heated rear seats |
| 31 | Vacant |
| 32 | Park Assist / Park distance control |
| 33 | Airbag system, hazard warning light switch |
| 34 | ASR, ESC, Tire Pressure Monitoring System (TPMS), air conditioning, reverse light switch, auto-dimming mirrors, Start-Stop system, sound symposer |
| 35 | Headlight range control, OBD2 diagnostic port, windshield camera, front radar sensor |
| 36 | Right LED / Xenon headlight |
| 37 | Left LED / Xenon headlight |
| 38 | Trailer towing module |
| 39 | Central locking (front passenger door), power window (right), heated & power-folding exterior mirror (right) |
| 40 | 12 V power sockets (cigarette lighter fuse) |
| 41 | Front passenger seat belt pretensioner |
| 42 | Central locking (rear doors), headlight washer system, windshield washer pump |
| 43 | Sound system amplifier |
| 44 | Trailer towing module |
| 45 | Power seat adjustment control module |
| 46 | 230 V power outlet inverter |
| 47 | Rear window wiper |
| 48 | Blind Spot Detect / Side Assist |
| 49 | Engine start circuit, clutch pedal switch |
| 50 | Electric tailgate / trunk lid release |
| 51 | SCR control module (AdBlue®) |
| 52 | USB charging ports |
| 53 | Heated rear window |
