When developing the next generation of Subaru Impreza, the creators tried to make the car attractive to a wider range of buyers, so it was decided to change the body shape from a station wagon to a hatchback. The updated car has many advantages: a spacious interior, well-thought-out design of instruments, a spacious luggage compartment, the maximum size of which reaches 1216 liters, a lightweight body and an excellent suspension. But only all this fades into the background, since the main differences between the Subaru Impreza are still the symmetrical all-wheel drive system (Symmetrical AWD) and the horizontally opposed engine (BOXER). Here, Subaru's developers have remained faithful to the company's traditional technology.
The power circuits of the Japanese car are protected by relays and fuses. The elements are installed in blocks that are located in the engine compartment and in the passenger compartment. The fuse diagrams of Subaru Impreza (GH, GE), as well as WRX and WRX STI 2007, 2008, 2009, 2010, 2011, 2012 with EL15 (1.5 l), EJ20 (2.0 l) and EJ25 ( 2.5 L Turbo) are considered.
In the engine compartment
Fuse box located on the right side, behind the protective cover.
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | A | Description |
| 1 | 30 | ABS, VDC systems |
| 2 | 25 | Cooling fan |
| 3 | 25 | Add. cooling fan |
| 4 | - | Empty |
| 5 | 10 | Radio cassette |
| 6 | 30 | Low beam headlamps |
| 7 | 15 | High beam headlamps |
| 8 | 20 | Reversing lights |
| 9 | 15 | Sound signal (horn) |
| 10 | 25 | Heated rear windows, heated side mirrors, defroster brushes |
| 11 | 15 | Fuel pump fuse |
| 12 | 10 | Automatic transmission control system |
| 13 | 7.5 | EGI + B engine management system |
| 14 | 15 | Direction indicators |
| 15 | 15 | Parking lights |
| 16 | 7.5 | Generator |
| 17 | 15 | Right headlight |
| 18 | 15 | Left headlight |
| Relay | ||
|
||
| Engine compartment relay box |
|---|
|
| Relay Box (Entry & start system) |
|---|
|
In the passenger compartment
The main unit is located on the driver's side, at the bottom of the dashboard behind a plastic cover. A relay board is located next to it. An additional relay board is located on the passenger side.
General view of the unit from the driver's side (together with the relay board).
| Diagram | ||
|---|---|---|
|
||
| No. | A | Decoding |
| 1 | 20 | Fog lamp relay |
| 2 | - | Empty |
| 3 | 15 | Central locking, central locking remote control system |
| 4 | 10 | Navigation system |
| 5 | 10 | Instrument cluster |
| 6 | 7.5 | Power side mirrors |
| 7 | 15 | Central display |
| 8 | 20 | Stop signals |
| 9 | 15 | Windshield wiper de-icer |
| 10 | 7.5 | Battery power |
| 11 | 7.5 | Direction indicators |
| 12 | 15 | Automatic transmission control system, engine management system, center display |
| 13 | 20 | Connector for additional equipment (in the center console) |
| 14 | 15 | Tail lamps, rear combination lights |
| 15 | - | Empty |
| 16 | 10 | Backlight |
| 17 | 15 | Heated seats |
| 18 | 10 | Reversing lights |
| 19 | - | Empty |
| 20 | 10 | Impreza cigarette lighter fuses, additional equipment. The fuse located directly on its back is also responsible for the cigarette lighter. |
| 21 | 7.5 | Starter relay |
| 22 | 15 | Air conditioning |
| 23 | 15 | Rear window wiper and washer |
| 24 | 15 | Navigation system |
| 25 | 15 | SRS system |
| 26 | 7.5 | Power window relay, cooling fan relay |
| 27 | 15 | Heater fan |
| 28 | 15 | |
| 29 | 15 | Fog lights |
| 30 | 30 | Windshield wiper and washer |
| 31 | 7.5 | Air conditioning, central display |
| 32 | - | Empty |
| 33 | 7.5 | ABS, VDC systems |
| Cabin relay blocks | |
|---|---|
| No. | Description |
| Next to the main one, from the driver's side | |
|
|
| F1 | Empty |
| F2 | Multifunctional control box (10A) |
| F3 | Windshield wiper / washer (15A) |
| F4 | Glow plug signal (7.5A) |
| 1 | Starter relay |
| 2 | Power window relay |
| 3 | Tailgate relay |
| 4 | Empty |
| 5 | Fog lamp relay |
| 6 | Rear fog lamp relay |
| 7 | Windshield heater relay |
| 8 | Seat heater relay |
| 9 | Direction indicator and alarm relay |
| Passenger side | |
|
|
| F1 | Engine management |
| F2 | |
| F3 | |
| 1 | Oxygen sensor relay |
| 2 | Fuel pump relay |
| 3 | Empty |
| 4 | Empty |
| 5 | Empty |
| 6 | Throttle control relay |
| 7 | Empty |
| 8 | Empty |
