The Toyota Land Cruiser 100 replaced the 80 Series, which had demonstrated exceptional reliability over the years. Consequently, the global popularity of the 100 Series was largely driven by the tremendous success of its predecessor. In this article, we will take a detailed look at the fuse box diagrams for the sixth generation Toyota Land Cruiser (J100 / J105 chassis codes) produced from 1997 to 2002.
Here you will find the locations and photos of the junction boxes. The fuse responsible for the “Cigarette lighter” is highlighted in bold.
In the engine compartment
Junction box locations.
General view of Fuse Box No. 2.
| Engine Compartment Fuse Assignment | ||
|---|---|---|
| No. | Description | Rating (A) |
| Fuse Box No. 1 | ||
|
||
| 1 | ALT-S: Charging system | 7.5 |
| 48 | MAIN: All components in fuse circuits “AM2”, “STARTER”, “EFI / ECD”, “HORN”, “HAZ-TRN”, “ABS NO. 2”, “HEAD (LH-UPR)”, “HEAD (RH-UPR)”, “HEAD (LH-LWR)”, “HEAD (RH-LWR)”, “GLOW”, “THROTTLE”, and “RADIO” | 100 |
| 49 | ALT: All components in fuse circuits “J/B NO. 2”, “MIR HTR”, “SEAT HTR”, “AM1 NO. 1”, “ACC”, “CDS FAN”, “HTR”, “AHC”, “ABS NO. 1”, and “HEAD CLEANER” | 140 |
| 50 | J/B NO. 2: All components in fuse circuits “ECU-B”, “FR FOG”, “DEFOG”, “AHC-B”, “OBD”, “TAIL”, “STOP”, “DOME”, “POWER”, “RR A/C”, and “RR HTR” | 100 |
| Fuse Box No. 2 | ||
|
||
| 2 | AM1: Starting system | 20 |
| 3 | A/C: Air conditioning system | 20 |
| 4 | POWER HTR: Power heater system | 10 |
| 5 | SEAT HTR: Heated seats | 15 |
| 6 | FUEL HTR: Fuel heater | 20 |
| 7 | MIR HTR: Heated exterior mirrors | 15 |
| 8 | HEAD CLEANER: Headlight washer system | 20 |
| 9 | CDS FAN: Condenser fan / Unused circuit | 20 |
| 10 | EFI / ECD: Multiport fuel injection / sequential multiport fuel injection system, emission control system, fuel pump | 20 |
| 11 | HORN: Horns | 10 |
| 12 | THROTTLE: Electronic throttle control system (ETCS) | 15 |
| 13 | RADIO: Audio system | 20 |
| 14 | HAZ-TRN: Hazard flashers, turn signal lights | 15 |
| 15 | AM2: Starting system, multiport fuel injection / sequential multiport fuel injection system, emission control system, all components in “IGN” fuse circuit | 30 |
| 16 | ECU-B1: Power door lock control system, power windows, rear window wiper and defogger, illuminated entry system, wireless remote control, gauges and meters, power exterior mirrors, rear fog lights, air conditioning | 10 |
| 17 | HEAD (LH-UPR): Left headlight (high beam) | 20 |
| 18 | HEAD (RH-UPR): Right headlight (high beam, front fog lights) | 20 |
| 19 | HEAD (LH-LWR): Left headlight (low beam) | 10 |
| 20 | HEAD (RH-LWR): Right headlight (low beam, headlight leveling system) | 10 |
| 42 | ABS NO. 1: Anti-lock braking system (ABS) | 40 |
| 43 | AHC: Active Height Control / Unused circuit | 50 |
| 44 | ACC: All components in “PWR OUTLET” circuit | 50 |
| 45 | ABS NO. 2: Anti-lock braking system (ABS) | 40 |
| 46 | STARTER: Starting system | 30 |
| 48 | MAIN: All components in fuse circuits “AM2”, “STARTER”, “EFI / ECD”, “HORN”, “HAZ-TRN”, “ABS NO. 2”, “HEAD (LH-UPR)”, “HEAD (RH-UPR)”, “HEAD (LH-LWR)”, “HEAD (RH-LWR)”, “GLOW”, “THROTTLE”, and “RADIO” | 100 |
| 49 | ALT: All components in fuse circuits “J/B NO. 2”, “MIR HTR”, “SEAT HTR”, “AM1 NO. 1”, “ACC”, “CDS FAN”, “HTR”, “AHC”, “ABS NO. 1”, and “HEAD CLEANER” | 140 |
| 50 | J/B NO. 2: All components in fuse circuits “ECU-B”, “FR FOG”, “DEFOG”, “AHC-B”, “OBD”, “TAIL”, “STOP”, “DOME”, “POWER”, “RR A/C”, and “RR HTR” | 100 |
| 51 | AM1 NO. 1: Starting system, headlight cleaner, all components in “ACC” fuse circuit | 80 |
| 52 | HTR: Climate control / Heater | 60 |
| 53 | GLOW: Engine glow plug system | 80 |
| Relay Box No. 2 Descriptions | |
|---|---|
|
|
| No. | Function |
| R1 | A/C Magnetic Clutch (MG CLT) |
| R2 | Mirror Heater (MIR HTR) |
| R3 | Accessories (ACC) |
| R4 | Active Height Control (AHC) |
| R5 | Ignition (IG1 NO. 1 / NO. 2) |
| R6 | |
| R7 | ABS Solenoid (ABS SOL) |
| R8 | Engine Control Module (EFI / ECD) |
| R9 | Horn |
| R10 | Headlight Dimmer |
| R11 | Starter |
| R12 | ABS Motor No. 2 (ABS MTR2) |
| R13 | Headlights (HEAD) |
| R14 | ABS Motor No. 1 (ABS MTR1) |
Battery Terminal Fuses
High-current fusible links located on the positive battery terminal:
- J/B NO. 2 – Fuses: “ECU-B”, “FR FOG”, “DEFOG”, “AHC-B”, “TAIL”, “STOP”, “DOME”, “POWER”, “OBD”, “RR A/C”, and “RR HTR” (100 A);
- ALT – Fuses: “J/B NO. 2”, “MIR HTR”, “AM1 NO. 1”, “ACC”, “CDS FAN”, “HTR”, and “ABS NO. 1” (140 A);
- MAIN – Fuses: “ECU-B”, “FR FOG”, “DEFOG”, “AHC-B”, “OBD”, “TAIL”, “STOP”, “DOME”, “POWER”, “RR A/C”, and “RR HTR” (100 A);
- ALT-S – Charging system (7.5 A).
In the passenger compartment
Left-Hand Drive (LHD): The fuse box is located on the lower right side of the dashboard, in the driver's footwell.
Right-Hand Drive (RHD): The fuse box is located in the passenger-side footwell.
Illustration of fuse box layout.
| Passenger Compartment Fuse Diagram | ||
|---|---|---|
|
||
| No. | Description | Rating (A) |
| 21 | MIR HTR: Power exterior mirrors | 10 |
| 22 | SRS airbag system, seat belt pretensioners | 15 |
| 23 | Toyota Land Cruiser 100 cigarette lighter, audio system, power antenna | 15 |
| 24 | IGN: Multiport fuel injection / sequential multiport fuel injection system, emission control system, SRS airbags, charge warning light | 10 |
| 25 | Interior lights, personal/map lights | 10 |
| 26 | AHC-IG: Active Height Control / Unused circuit | 20 |
| 27 | DIFF: Front and rear differential lock system | 20 |
| 28 | GAUGE: Gauges and meters, warning lights and chimes (except charge warning light, SRS airbag, and open door warning), backup lights, air conditioning, electronically controlled automatic transmission (ECT), wireless remote control, electric winch | 15 |
| 29 | WIPER: Windshield wipers and washer, rear window wiper and washer | 20 |
| 30 | IDLE: Engine idle speed control system | 7.5 |
| 31 | FR FOG: Front fog lights | 15 |
| 32 | STOP: Brake lights, high-mount stop light | 15 |
| 33 | A/C: Air conditioning system | 30 |
| 34 | DEFOG: Rear window defogger | 20 |
| 35 | ECU-B: Power tilt and telescopic steering column | 15 |
| 36 | TAIL: Tail lights, license plate lights, parking lights | 15 |
| 37 | ANS-V: Unused circuit | 15 |
| 38 | OBD: On-Board Diagnostics (OBD-II) system | 10 |
| 39 | RR HTR: Rear heater / Air conditioning system | 10 |
| 40 | ECU-IG: Anti-lock braking system (ABS), cruise control, power antenna | 15 |
| 41 | PWR OUTLET: Auxiliary power outlets | 15 |
| 47 | POWER: Power door locks, power windows, power sunroof | 30 |
| Relay Locations (Rear Side of Junction Box) | |
|---|---|
|
|
| No. | Function |
| R1 | Fuel Pump / Circuit Opening (C/OPN) |
| R2 | Fuel Pump Relay (FUEL PMP) |
| R3 | Door Lock – Lock (D/L L) |
| R4 | Spill Valve (SPIL VLV) |
| R5 | Starter Cut (ST CUT) |
| R6 | Door Lock – Unlock (D/L U) |
| R7 | Front Fog Lights (FR FOG) |
| R8 | Unused / Empty |
| R9 | Rear Defogger (DEFOG) |
| R10 | Power Windows & Sunroof (POWER) |
| R11 | Rear Heater (RR HTR) |
| R12 | Interior Lights (DOME) |
| R13 | Tail Lights / Side Marker Lights (TAIL) |
