The 110-series Toyota Mark II sedan features a sportier exterior design and a completely redesigned interior. The discontinuation of sister models Chaser and Cresta led to a sharp surge in demand for the Mark II, making it exceptionally popular in Japan.
This guide provides detailed fuse box diagrams and circuit layouts for the 9th-generation Toyota Mark II (chassis codes X110, X115; X platform; 2000–2007). Below you will find component locations, photographic references, and circuit assignments for each power distribution block. The fuse for the “Cigarette Lighter” circuit is highlighted in bold.
Engine Compartment
Two power distribution blocks are located on the left side of the engine compartment:
- #1 – Main Fuse and Relay Box;
- #2 – Auxiliary Relay Box.
Fuse Box #1
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Description | A |
| ALT-S | Charging system | 5 |
| MRX-B | Charging system Engine management system Electronic automatic transmission control ABS (Anti-lock braking system) SRS airbag system Multiplex communication system Central power door locks (Sedan) Ignition key reminder chime Engine immobilizer Seatbelt reminder & pretensioner system Instrument cluster Automatic headlight control system Automatic climate control system Multiplex communication system (Power tailgate – Station Wagon) Power tailgate closer “EASY CLOSE” (Station Wagon) Audio system (Models from 12/2003) |
5 |
| H-LPUPR | Front fog lamps (Sedan) | 5 |
| A / C | Automatic climate control | 10 |
| H-LPLUPR | Instrument cluster, headlights, fog lamps (Sedan) | 15 |
| ETCS |
|
10 |
| HORN | Horn | 10 |
| H-LPLLWR | Headlamps (Low beam) | 15 |
| H-LPLUPR | Instrument cluster, headlights, fog lamps (Sedan) | 15 |
| H-LPRUPR | Front fog lamps (Sedan) | 15 |
| INJ | Engine management system (1JZ-FSE engine) | 15 |
| H-LPRLWR | Headlamps (Low beam) | 15 |
| RADIO No. 1 | Audio system (Models from 12/2003) | 15 |
| POWER OUTLET |
Auxiliary power outlet (Station Wagon) | 15 |
| TURN-HAZ | Turn signal and hazard warning flasher | 15 |
| B / DECU |
|
20 |
| TEMS | Electronically Modulated Suspension (TEMS) | 15 |
| EFI |
|
25 |
| DOOR |
|
20 |
| FRDEF | Heated exterior mirrors & windshield wiper de-icer | 25 |
| AM2 | Starting & ignition system | 30 |
| F / PMP | Fuel injection system (1JZ-FSE engine) | 25 |
| FAN | Electric cooling fan (1JZ-GTE engine) | 60 |
| Electric cooling fan (1JZ-GE engine) | 30 | |
| DEFOG | Rear window defogger (Station Wagon) | 30 |
| Rear window defogger (Sedan) | 40 | |
| ABS1 ABS 2 |
Anti-lock braking system (ABS) | 40 |
| HTR | Blower motor / Climate control | 40 |
| ALT |
|
100 |
| 120 | ||
| 140 | ||
| Relays | ||
|
||
| R1 | Fuel injection system relay | |
| R2 | Starter relay | |
| R3 | ABS pump relay | |
| R4 | Headlight relay | |
| R5 | Toyota Mark II fuel pump relay | |
| R6 | Fuel injector relay | |
| R7 | ABS pump relay | |
| R8 | ||
| R9 | Fuel injection system relay | |
| R10 | High-beam headlight relay | |
Relay Box #2
Diagram.
|
|
| No. | Circuit Description |
| R1 |
|
| R2 | Rear window defogger relay |
| R3 | Horn relay |
| R4 | Air conditioning compressor relay |
| R5 | Windshield wiper de-icer relay |
| R6 | Heated mirror relay |
| R7 | Cooling fan relay |
| R8 | Fuel pump relay |
| R9 | Cooling fan relay |
Passenger Compartment
General layout of electronic control units (ECUs).
|
|
| No. | Component / Module |
| 1 | Automatic transmission control module (TCM) (Models from 10/2002) |
| 2 | Front left acceleration sensor |
| 3 | Navigation system control module |
| 4 | Multiplex network gateway ECU |
| 5 | Central junction block |
| 6 | Body control module (BCM) |
| 7 | TEMS control module |
| 8 | Passenger-side fuse box |
| 9 | Immobilizer transponder amplifier |
| 10 | Vehicle Stability Control (VSC) warning buzzer |
| 11 | SRS airbag control module |
| 12 | Driver-side fuse box |
| 13 | Shift lock control module |
| 14 | 4WD deceleration sensor |
| 15 | Yaw rate and deceleration sensor (VSC) |
Driver-Side Fuse Box
Located in the driver's footwell behind a plastic access cover.
General view of the distribution box.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Description | A |
| GAUGE | Charging system, engine management system, electronic automatic transmission control | 5 |
| CORNERING LAMP |
Cornering lamps / Turn signals | 5 |
| STARTER | Starting system, engine management system | 5 |
| BACK-UP |
|
7.5 |
| IG1 | Electric cooling fan | 7.5 |
| IG2 | Ignition system, engine management system | 20 |
| IGN | Engine management system, electronic automatic transmission control, SRS airbag system, engine immobilizer, cruise control system | 10 |
| WASHER | Windshield and rear window washer system | 15 |
| REAR WIPER |
Rear window wiper & washer | 10 |
| STOP | Stop / Brake lamps | 15 |
| ECU-IG |
|
15 |
| D FRONT POWER WINDOW |
Driver-side front power window (Models up to 05/2003) | 20 |
| D POWER SEAT |
Driver-side power seat | 30 |
| CIG | Toyota Mark II 110 cigarette lighter fuse Auxiliary power outlet (Station Wagon) |
15 |
| WIPER | Windshield wipers & washer | 20 |
Passenger-Side Fuse Box
Located in the front passenger footwell (left side).
Sample photograph shown below.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Description | A |
| PANEL1 | Clock & illumination | 5 |
| PANEL | Instrument panel & switch illumination | 25 |
| DOME1 |
|
5 |
| DOME2 | Clock | 5 |
| REAR FOG |
Rear fog lamps | 7.5 |
| ECU-B |
|
10 |
| FR FOG | Front fog lamps | 15 |
| TAIL |
|
10 |
| MIRROR HEATER |
Heated exterior mirrors & windshield wiper de-icer | 15 |
| P FRONT POWER WINDOW |
Passenger-side front power window | 20 |
| D REAR POWER WINDOW |
Driver-side rear power window | 20 |
| P REAR POWER WINDOW |
Passenger-side rear power window | 20 |
| SUN ROOF | Power sunroof | 30 |
| P POWER SEAT |
Passenger-side power seat | 30 |
