The Ractis subcompact MPV replaced the FunCargo, which was discontinued in 2005. Produced specifically for the Japanese domestic market (JDM), it belongs to Toyota’s new generation of compact vehicles engineered to be comfortable, economical, and safe. In this article, we take a detailed look at the fuse and relay box diagrams for the first-generation Toyota Ractis (chassis codes P100, P105; B platform) produced from 2005 to 2010.
Here you will find fuse box location diagrams and photos. The fuses responsible for the “Cigarette Lighter” and “Fuel Pump” are highlighted in bold.
Engine Compartment
The fuse box is located near the battery.
Location example relative to the battery.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Protected | A |
| 1 | Unused | - |
| 2 | Starter system, sequential multiport fuel injection system (SFI) | 15 |
| 3 | Sequential multiport fuel injection system (SFI) | 20 |
| Horn (1NZ-FE, 2NZ-FE, 2SZ-FE, 2ZR-FE, 1KR-FE engines) | 10 | |
| Sequential multiport fuel injection system (1ND-TV engine) | 30 | |
| 4 | Horn (1KR-FE, 1ND-TV engines) | 10 |
| EFI - Sequential multiport fuel injection system (1NZ-FE, 2NZ-FE, 2SZ-FE, 2ZR-FE, 1KR-FE engines) | 20 | |
| ECD - Diesel sequential multiport fuel injection system (TMMF models, produced from Nov 2008) | 30 | |
| 5 | Unused | - |
| 6 | Unused | - |
| 7 | Unused | - |
| 8 | Unused | - |
| 9 | Unused | - |
| 10 | Unused | - |
| 11 | FR DEF - Windshield de-icer | 20 |
| 12 | ABS2 / VSC2 - Anti-lock brake system, vehicle stability control system | 30 |
| 13 | H-LP MAIN - Headlights with DRL: “H-LP LH”, “H-LP LO LH”, “H-LP HI LH”, “H-LP HI RH” | 30 |
| 14 | ST - Starter system | 30 |
| 15 | S-LOCK - Steering column lock system | 20 |
| 16 | DOME - Interior lighting, map lights, anti-theft system, audio system, wireless remote control system | 15 |
| 17 | ECU-B - Engine immobilizer system, daytime running light system, front passenger occupant classification system, power windows, power door locks, anti-theft system, instrument cluster and sensors | 7.5 |
| 18 | ALT-S - Charging system | 7.5 |
| 19 | ETCS - Electronic throttle control system, sequential multiport fuel injection system | 10 |
| 20 | Turn signal lights, hazard flashers | 10 |
| 21 | AMT - Multi-Mode Manual Transmission (MMT) | 50 |
| BBC - Stop & Start system | 40 | |
| 22 | H-LP RH - Right headlight | 10 |
| 23 | H-LP LH - Left headlight | 10 |
| 24 | EFI2 - Gasoline sequential multiport fuel injection system | 10 |
| ECD2 - Diesel sequential multiport fuel injection system | 10 | |
| 25 | ECD3 - Diesel multiport fuel injection system / sequential multiport fuel injection system | 7.5 |
| 26 | HTR SUB2 - PTC heater (435 W type) | 40 |
| HTR SUB1 - PTC heater (600 W type) | 50 | |
| 27 | EPS - Electric power steering | 50 |
| 28 | ABS1 / VSC1 - Anti-lock brake system (ABS), vehicle stability control system (VSC) | 50 |
| 29 | HTR - Air conditioning / climate control system | 40 |
| 30 | RDI - Radiator cooling fan | 30 |
| 31 | HTR SUB1 - PTC heater (435 W type) | 30 |
| HTR SUB2 - PTC heater (600 W type) | 30 | |
| 32 | H-LP CLN / PWR HTR - Headlight cleaners, power heater | 30 |
| HTR SUB3 - PTC heater (600 W type) | 30 | |
| R1 | Starter relay | |
| R2 | Radiator cooling fan relay | |
| R3 | Heater / blower relay | |
Passenger Compartment
The fuse box is located behind the glove box.
Overview of the fuse box cover.
| Diagram | ||
|---|---|---|
|
||
| No. | Circuit Protected | A |
| 1 | TAIL - Side marker lights, tail lights, license plate lights, multiport fuel injection system / sequential multiport fuel injection system | 10 |
| PANEL2 - Engine immobilizer system, smart entry and start system, front fog lights, instrument illumination, headlight reminder chime, multi-mode manual transmission, rear fog light, steering lock, tail lights, wireless door lock control | 7.5 | |
| 2 | PANEL1 - Instrument panel illumination, dashboard brightness control, instrument cluster and sensors | 7.5 |
| 3 | Rear window defogger, air conditioning system | 7.5 |
| 4 | D DOOR - Driver power window | 20 |
| 5 | Rear left power window | 20 |
| 6 | Rear right power window | 20 |
| 7 | Unused | - |
| 8 | CIG - Toyota Ractis cigarette lighter fuse, 12V power outlet | 15 |
| 9 | ACC - Power door locks, power outer mirrors, audio system | 7.5 |
| 10 | Unused | - |
| 11 | ID / UP / MIR HTR - Multiport fuel injection system / sequential multiport fuel injection system, heated mirrors | 10 |
| 12 | Unused | - |
| 13 | Unused | - |
| 14 | Rear fog lights | 7.5 |
| 15 | IGN - Sequential multiport fuel injection system, engine immobilizer system, SRS airbag system, front passenger occupant classification system | 7.5 |
| 16 | Gauges, instrument cluster, and sensors | 7.5 |
| 17 | Passenger seat heater | 15 |
| 18 | Driver seat heater | 15 |
| 19 | Windshield wipers | 20/25 |
| 20 | Rear window wiper | 15 |
| 21 | Windshield washer | 15 |
| 22 | Daytime running light (DRL) system, anti-lock brake system (ABS), electric power steering (EPS), power windows, power door locks, anti-theft system, electric cooling fan | 10 |
| 23 | Charging system, turn signals, hazard flashers, headlight leveling system, instrument panel illumination, shift lock system, rear window defogger, air conditioning system, automatic transmission system | 10 |
| 24 | OBD - On-board diagnostics system (OBD-II) | 7.5 |
| 25 | STOP - Stop lights, high-mount stop light, multiport fuel injection system / sequential multiport fuel injection system, shift lock system, anti-lock brake system (ABS) | 10 |
| 26 | Unused | - |
| 27 | D / L - Power door lock system | 25 |
| 28 | Front fog lights | 15 |
| 29 | Unused | - |
| 30 | Side marker lights, tail lights, license plate lights, multiport fuel injection system / sequential multiport fuel injection system | 10 |
| 31 | AM1 - Ignition switch, sequential multiport fuel injection system | 25 |
Additional relay blocks are located above the main fuse unit.
| Diagram | |
|---|---|
|
|
| No. | Component |
| 1 | ACC (Accessory relay) |
| 2 | Ignition system relay |
| 3 | Heater / blower relay |
| 4 | Rear fog lights relay |
| 5 | Front fog lights relay |
| 6 |
|
