The japanese minivan power circuits are protected by fuses. The elements are installed in distribution blocks located in the engine compartment and in the passenger compartment.
In this article, we will take a detailed look at the fuse box diagrams for the Toyota Sienna (XL30) 3rd generation 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017 release.
In the engine compartment
Fuse box located in the engine compartment (left) near the battery.
Access example.
| Diagram | ||
|---|---|---|
|
||
| No. | Description | A |
| 1 | Headlamp leveling system (vehicles with HID headlights only) | 7.5 |
| 2 | PCS (Pre-collision system), dynamic radar cruise control system | 7.5 |
| 3 | Starting system, multiport fuel injection system / sequential multiport fuel injection system | 7.5 |
| 4 | Left Headlamp (low beam) (only vehicles with HID headlights) | 20 |
| 5 | Right Headlamp (low beam) (only vehicles with HID headlights) | 20 |
| 6 | Multiport fuel injection system / sequential multiport fuel injection system, automatic transmission | 7.5 |
| 7 | Multiport fuel injection system / sequential multiport fuel injection system | 10 |
| 8 | Right Headlamp (high beam) | 10 |
| 9 | Left Headlamp (high beam) | 10 |
| 10 | Spare fuse | 10 |
| 11 | 15 | |
| 12 | 20 | |
| 13 | Air conditioner magnetic clutch | 7.5 |
| 14 | inverter | 20 |
| 15 | PTC heater (1AR-FE engine only) | 50 |
| 16 | 30 | |
| 17 | 30 | |
| 18 | Rear air conditioning | 40 |
| 19 | Power tailgate | 30 |
| 20 | Third power seat (2GR-FE engine only) | 30 |
| 21 | Air conditioning | 50 |
| 22 | Pre-crash seat belt (2GR-FE engine only) | 30 |
| 23 | SEAT WITH AUTOMATIC ACCESS | 30 |
| 24 | Electric cooling fans | 60 |
| 25 | Direction indicators, sensors and meters | 15 |
| 26 | Rear Seat Entertainment | 15 |
| 27 | Outside rearview mirror control, outside rearview mirror heaters (2GR-FE engine only) | 10 |
| 28 | Audio system | 30 |
| 29 | Integrated vehicle dynamics control, ABS, vehicle stability control | 30 |
| 30 | Launch system | 30 |
| 31 | Horn, alarm, Left Headlamp (low beam), Right Headlamp (low beam) | 40 |
| 32 | HID Headlamps (only vehicles with HID) | 40 |
| 32 | Spare fuse (only vehicles without HID headlights) | 30 |
| 33 | Fuses "ST NO.2", "GAUGE NO.2" and "IG2" (only vehicles without electronic key system) | 30 |
| 34 | Integrated vehicle dynamics control, ABS, vehicle stability control | 50 |
| 35 | Charging system, horn, alarm, left headlight (low beam), right headlight (low beam), fog light, heated outside rearview mirrors, heated rear window, defroster | 140 |
| 36 | Audio system | 15 |
| 37 | Vanity Lights, Personal / Interior Lights, Personal Lights, Engine Switch Lights, Rear Ceiling Lights, Door Lights, Luggage Compartment Lights, Gauges & Counters, Clock | 7.5 |
| 38 | Main Body ECU, Smart Key System, Wireless Remote Control, Power Tailgate, Power Sliding Door, Rear View Monitor, Multi-Information Display, Power Window, Outside Rearview Mirror Control, Steering Angle Sensor, Auto Anti-Glare Interior rearview mirrors, AUTO Remote control ACCESS SEAT, front passenger classification system | 10 |
| 39 | Multiport fuel injection system / sequential multiport fuel injection system | 10 |
| 40 | 20 | |
| 41 | Steering lock system (only vehicles with smart key system) | 20 |
| 42 | Charging system | 7.5 |
| 43 | Multiport fuel injection system / sequential multiport fuel injection system, "IG NO.2" and "IG2" fuses | 25 |
| 44 | Air conditioning | 7.5 |
| 45 | Multiplex communication system, starting system (only for vehicles with smart key system) | 7.5 |
| 46 | Multiport fuel injection system / sequential multiport fuel injection system, "ECT" and "EFI NO.2" fuses | 25 |
| 47 | Smart key system (only for vehicles with smart key system) | 5 |
| 48 | Daytime running lamps system, fuses "HLP LH (HI)" and "H-LP RH (HI)" | 30 |
| 49 | Electric power steering | 60 |
In the passenger compartment
Fuse box located under the dashboard (on the driver's side) behind a plastic cover.
Access example.
| Diagram | ||
|---|---|---|
|
||
| No. | Decoding | A |
| 1 | Sockets | 15 |
| 2 | Audio system, navigation system, rear seat entertainment system | 7.5 |
| 3 | Main body ECU, clock, shift lock system, electric rearview mirror control, multiplex communication system | 10 |
| 4 | CIG Sockets, Sienna cigarette lighter fuse | 15 |
| 5 | Hazard warning lights, illuminated lights, navigation system, multi-information display, automatic transmission, multiport fuel injection system / sequential multiport fuel injection system, charging system | 10 |
| 6 | Multiplex communication system, brake lights, navigation system, vehicle stability control system, Active Torque Control 4WD, intuitive parking assistant, automatic anti-glare interior mirror, pre-crash seat belt, outside rearview mirror, heated seat, TPMS, yaw rate sensor and acceleration, steering angle sensor, auto-access seat, main body ECU | 10 |
| 7 | Rear power window (left) | 20 |
| 8 | Electric door locking system | 15 |
| 9 | Power Front Seat (Right) | 30 |
| 10 | Moon roof | 30 |
| 11 | Rear power window (right) | 20 |
| 12 | Front power windows (right) | 20 |
| 13 | Front Power Seat Left, Driver Position Memory System | 30 |
| 14 | Brake lights, ABS, Vehicle Stability Control, Rear Combination Light, High Brake Light, Automatic Transmission, Shift Lock System, Multiplex Communication System, Power Third Seat Switch, Multiport Fuel Injection System / Sequential Multiport Fuel Injection System, trailer lights (stop lights) | 10 |
| 15 | Front power windows (left side) | 20 |
| 16 | Electric sliding door (left) | 25 |
| 17 | Active 4WD torque control | 7.5 |
| 18 | Launch system | 10 |
| 19= | Pressure gauges and counters, multi-information display | 7.5 |
| 20 | Automatic transmission, multiport fuel injection system / sequential multiport fuel injection system, SRS airbag system, front seat passenger classification system, steering lock system, smart key system, starting system, fuel pump | 7.5 |
| 21 | A / C system, navigation system, front passenger seat belt reminder light, audio system, steering switch, intuitive park assist switch, personal / interior light master switch, shift lever light, turn switch, door lock master switch electric, clock, quarter-turn power window switch, seat heating switch, emergency flashers, heated rear window switch, vehicle stabilization switch, console lighting, power slide switch | 10 |
| 22 | Rear lights, trailer lights (rear lights), license plate lights, rear combination lights | 10 |
| 23 | Rear window wiper and wiper | 7.5 |
| 24 | Power windows | 15 |
| 25 | Automatic high beam | 10 |
| 26 | Wiper | 30 |
| 27 | Windshield washer | 20 |
| 28 | Rear window wiper | 20 |
| 29 | Rear window washer | 15 |
| 30 | Air conditioning | 10 |
| 31 | Shift interlock system, multiport fuel injection system / sequential multiport fuel injection system | 7.5 |
| 32 | Collision avoidance, pre-collision seatbelt, dynamic radar cruise control, electric power steering, rain sensors, windshield wipers, driver memory, power sliding door, power third seat, power tailgate, multiplex communication system | 10 |
| 33 | Electric sliding door (right) | 25 |
| 34 | On-board diagnostic system | 7.5 |
| 35 | Seat heating (left) | 15 |
| 36 | Seat heating (right) | 15 |
