Fuses and relays Toyota Wish (XE10; 2003–2009)

Table of Contents

Most electrical circuits in this minivan are protected by fuses, while high-current components are powered through relays. Protective devices are installed in fuse/relay boxes located in both the engine compartment and the passenger compartment.


These fuse diagrams apply to Toyota Wish models produced from 2003 to 2009 (chassis codes ZNE10G, ZNE14G, ANE10G, ANE11W; Toyota MC platform; 2WD & 4WD) equipped with 1ZZ-FE (1.8L) and 1AZ-FSE (2.0L D-4) engines.

Passenger Compartment


Component Location (Dashboard). 1 – Fuel pump relay, 2 – Engine ECU, 3 – Fuse block, 4 – Electric Power Steering (EPS) ECU, 5 – Engine immobilizer ECU, 6 – Headlight leveling ECU, 7 – Power inverter relay (models from 04/2003), 8 – Under-dash junction box, 9 – ABS ECU, 10 – Airbag (SRS) ECU, 11 – Front fog lamp relay, 12 – Windshield wiper de-icer relay, 13 – Turn signal flasher relay

Under-Dash Junction Box

No. 8 in the illustration.


General view.

Diagram
Code Description Rating (A)
ECU-ACC
  • Ignition key interlock solenoid,
  • Power side mirrors,
  • Key-in-ignition and lights-on reminder chime,
  • Audio system (models with built-in amplifier),
  • Audio system (models with separate amplifier through 09/2005),
  • Audio system, navigation system, Blind Corner Monitor system, and rearview camera system (models through 09/2005),
  • Engine & CVT control system and shift position indicator lamps (1AZ-FSE from 09/2005),
  • Audio system, navigation system, Blind Corner Monitor system, rearview camera system, and rear display (models through 09/2005),
  • Engine and automatic transmission control system, shift selector illumination (1ZZ-FE 2WD from 09/2005),
  • Engine & CVT control system and shift position indicator lamps (1AZ-FSE from 09/2005),
  • Audio system, navigation system, and rearview camera system (models from 09/2005),
  • Audio system, navigation system, Blind Corner Monitor system, rearview camera system, and rear display (models from 09/2005),
  • Automatic transmission control system
 7.5
ECU-IG
  • Charging system,
  • Cooling fan motor,
  • Anti-lock Braking System (ABS) (2WD without VSC),
  • Anti-lock Braking System (ABS) (4WD),
  • Ignition key interlock solenoid,
  • Electric Power Steering (EPS),
  • Audio system, navigation system, Blind Corner Monitor system, and rearview camera system,
  • Headlights (models with HID/Xenon headlights),
  • Auxiliary power outlet (12V socket),
  • Anti-lock Braking System (TRC and VSC models),
  • Central door locking (models with "Smart Entry & Start" system),
  • Audio system, navigation system, Blind Corner Monitor system, rearview camera system, and rear display
 7.5
GAUGE
  • Automatic transmission control system and shift selector backlighting (1ZZ-FE, except 2WD from 09/2005),
  • Power windows,
  • Central door locking,
  • Key-in-ignition and lights-on reminder system,
  • Seat belt warning system,
  • Power sunroof,
  • Audio system, navigation system, Blind Corner Monitor system, and rearview camera system,
  • Turn signal and hazard warning lights,
  • Automatic headlight leveling system,
  • Reverse lamps,
  • Windshield wiper de-icer,
  • Engine & CVT control system and shift position indicator lamps (1AZ-FSE 2WD from 09/2005),
  • Audio system, navigation system, Blind Corner Monitor system, rearview camera system, and rear display,
  • Automatic transmission control system and shift selector backlighting (1ZZ-FE 2WD from 09/2005),
  • Automatic transmission control system and shift selector backlighting (1AZ-FSE from 09/2005)
 7.5
PANEL
  • Digital clock,
  • Front fog lamps,
  • Rear fog lamps,
  • Instrument panel backlighting
 7.5
RR FOG Rear fog lamps 7.5
A/C
  • Seat belt warning system,
  • Digital clock,
  • Automatic climate control system,
  • Rear window defogger and heated side mirrors
 10
ME HTR Heated side mirrors 10
TAIL
  • Key-in-ignition and lights-on reminder system,
  • Headlights (1ZZ-FE without HID/Xenon headlights),
  • Front fog lamps,
  • Rear fog lamps,
  • Instrument panel backlighting,
  • Parking / Clearance lamps
 10
ACC Auxiliary power outlet (12V socket) 15
FR DEF Windshield wiper de-icer 15
FR FOG Front fog lamps 15
IGN
  • Ignition system,
  • Engine management system (1ZZ-FE, except 2WD from 09/2005),
  • Automatic transmission control system and shift selector backlighting (1ZZ-FE, except 2WD from 09/2005),
  • Supplemental Restraint System (SRS airbags),
  • Engine immobilizer system,
  • Engine & CVT control system and shift position indicator lamps (1AZ-FSE),
  • Engine and automatic transmission control system and shift selector backlighting (1ZZ-FE 2WD from 09/2005)
 15
RR WIPER Rear window wiper and washer 15
STOP
  • Engine management system (1ZZ-FE, except 2WD from 09/2005),
  • Automatic transmission control system and shift selector backlighting (1ZZ-FE, except 2WD from 09/2005),
  • Anti-lock Braking System (ABS) (2WD without VSC),
  • Anti-lock Braking System (ABS) (4WD),
  • Shift lock solenoid / Key interlock,
  • Brake lights,
  • Engine & CVT control system and shift position indicator lamps (1AZ-FSE),
  • Anti-lock Braking System (TRC and VSC models),
  • Engine and automatic transmission control system and shift selector backlighting (1ZZ-FE 2WD from 09/2005)
 15
WIPER
  • Windshield wiper and washer,
  • Rear window wiper and washer
 20
THROUGH Interior dome lights 25
RR DEF Rear window defogger and heated side mirrors 25
FRP / W
  • Power windows,
  • Central door locking
 30
PWR
  • Power windows,
  • Power sunroof
 30

Engine Compartment


Component Location (Engine Compartment).

  1. Fuse and Relay Box No. 1
  2. Relay Box No. 2
  3. Relay Box No. 3

Fuse Box No. 1


General view.

Diagram
Code Description Rating (A)
ECU-B
  • Ignition system,
  • Engine management system (1ZZ-FE, except 2WD from 09/2005),
  • Automatic transmission control system and shift selector backlighting (1ZZ-FE, except 2WD from 09/2005),
  • Anti-lock Braking System (ABS) (2WD without VSC),
  • Anti-lock Braking System (ABS) (4WD),
  • Power windows,
  • Central door locking,
  • Key-in-ignition and lights-on reminder chime,
  • Seat belt warning system,
  • Power sunroof,
  • Engine immobilizer system,
  • Instrument cluster,
  • Audio system, navigation system, Blind Corner Monitor system, and rearview camera system (models through 09/2005),
  • Digital clock,
  • Automatic lighting control system,
  • Interior dome lights,
  • Instrument panel backlighting,
  • Automatic climate control system,
  • Engine & CVT control system and shift position indicator lamps (1AZ-FSE),
  • Anti-lock Braking System (TRC and VSC models),
  • Audio system, navigation system, Blind Corner Monitor system, rearview camera system, and rear display (models through 09/2005),
  • Engine and automatic transmission control system and shift selector backlighting (1ZZ-FE 2WD from 09/2005),
  • Audio system, navigation system, and rearview camera system (models from 09/2005)
 7.5
ALT-S Charging system / Alternator sensor 10
DOME
  • Instrument cluster,
  • Headlights (1ZZ-FE without HID/Xenon headlights),
  • Interior dome lights
 10
ATC-S
  • Engine & CVT control system and shift position indicator lamps (1AZ-FSE),
  • Engine and automatic transmission control system and shift selector backlighting (1ZZ-FE 2WD from 09/2005)
 10
HORN Horn 10
TURN HAZ Turn signal and hazard warning lights 10
AC INV AC power inverter outlet 15
EFI 2
  • Ignition system,
  • Engine & CVT control system and shift position indicator lamps (1AZ-FSE)
 15
EFI
  • Engine management system (1ZZ-FE, except 2WD from 09/2005),
  • Automatic transmission control system and shift selector backlighting (1ZZ-FE, except 2WD from 09/2005),
  • Engine immobilizer system,
  • Engine and automatic transmission control system and shift selector backlighting (1ZZ-FE 2WD from 09/2005)
 15
H-LP LH Left headlight (1ZZ-FE without HID/Xenon headlights) 15
H-LP RH Right headlight (1ZZ-FE without HID/Xenon headlights) 15
RAD №1
  • Audio system (models with built-in amplifier),
  • Audio system (models with separate amplifier from 09/2005),
  • Audio system, navigation system, Blind Corner Monitor system, and rearview camera system (models through 09/2005),
  • Audio system, navigation system, Blind Corner Monitor system, rearview camera system, and rear display,
  • Audio system, navigation system, and rearview camera system (models from 09/2005),
  • Automatic transmission control system
 15
EFI
  • Engine immobilizer system,
  • Engine & CVT control system and shift position indicator lamps (1AZ-FSE)
 20
SECTION
  • Anti-lock Braking System (ABS) (2WD without VSC),
  • Anti-lock Braking System (TRC and VSC models)
 25
ABS №2 Anti-lock Braking System (ABS) (4WD) 30
CDS Condenser cooling fan motor (except 1ZZ-FE 2WD) 30
RDI Radiator cooling fan motor 30
ABS №1
  • Anti-lock Braking System (ABS) (2WD without VSC),
  • Anti-lock Braking System (ABS) (4WD)
 30
SUPPORT Automatic climate control / Heater blower motor 40
MAIN
  • Instrument cluster,
  • Headlights (1ZZ-FE without HID/Xenon headlights),
  • Headlights (models with HID/Xenon headlights),
  • Rear fog lamps,
  • Automatic lighting control system,
  • Headlights (1AZ-FSE through 09/2005)
 40
ABS №1 Anti-lock Braking System (TRC and VSC models) 50
EMPS Electric Power Steering (EPS) 50
EVERYTHING
  • Ignition system,
  • Key-in-ignition and lights-on reminder system,
  • Digital clock,
  • Headlights (1ZZ-FE without HID/Xenon headlights),
  • Front fog lamps,
  • Rear fog lamps,
  • Automatic lighting control system,
  • Instrument panel backlighting,
  • Parking / Clearance lamps,
  • Rear window defogger and heated side mirrors
 120

Relay Box No. 2

Diagram.

Code Protected Circuit Rating (A)
ST
  • Starter system,
  • Engine management system (1ZZ-FE, except 2WD from 09/2005),
  • Engine & CVT control system and shift position indicator lamps (1AZ-FSE),
  • Engine and automatic transmission control system and shift selector backlighting (1ZZ-FE 2WD from 09/2005)
 7.5

Relay Box No. 3

Diagram.

Code Protected Circuit Rating (A)
H-LPLH (LWR)
  • Low beam headlight (Left) (1AZ-FSE through 09/2005),
  • Low beam headlight (Left) (models with HID/Xenon headlights)
 15
H-LP LH (UPR)
  • High beam headlight (Left) (1AZ-FSE through 09/2005),
  • High beam headlight (Left) (models with HID/Xenon headlights)
 15
H-LPRH (LWR)
  • Low beam headlight (Right) (1AZ-FSE through 09/2005),
  • Low beam headlight (Right) (models with HID/Xenon headlights)
 15
H-LP RH (UPR)
  • High beam headlight (Right) (1AZ-FSE through 09/2005),
  • High beam headlight (Right) (models with HID/Xenon headlights)
 15
GAUGE IG2
  • Charging system,
  • Engine management system (1ZZ-FE, except 2WD from 09/2005),
  • Automatic transmission control system and shift selector backlighting (1ZZ-FE, except 2WD from 09/2005),
  • Anti-lock Braking System (ABS) (2WD without VSC),
  • Anti-lock Braking System (ABS) (4WD),
  • Supplemental Restraint System (SRS airbags),
  • Electric Power Steering (EPS),
  • Key-in-ignition and lights-on reminder chime,
  • Seat belt warning system,
  • Engine immobilizer system,
  • Instrument cluster,
  • Audio system, navigation system, Blind Corner Monitor system, and rearview camera system (models through 09/2005),
  • Headlights (models with HID/Xenon headlights),
  • Instrument panel backlighting,
  • Parking / Clearance lamps,
  • Engine & CVT control system and shift position indicator lamps (1AZ-FSE),
  • Anti-lock Braking System (TRC and VSC models),
  • Audio system, navigation system, Blind Corner Monitor system, rearview camera system, and rear display (models through 09/2005),
  • Engine and automatic transmission control system and shift selector backlighting (1ZZ-FE 2WD from 09/2005)
 7.5
