Introduced in 2000, the Volvo S60 sedan was positioned below the executive S80 in Volvo’s lineup. It is built on the same Volvo P2 platform, configured for front-wheel drive (FWD) or all-wheel drive (AWD). With this model, Volvo emphasized a radical design shift compared to its previous generations. This guide provides detailed fuse box diagrams and assignments for the first-generation Volvo S60 (chassis code RS / RH (384); P2 platform) covering model years 2000 through 2009.
Below you will find the locations, diagrams, and photos of the power distribution boxes. Fuses for the “Cigarette Lighter” and “Fuel Pump” are highlighted in bold.
The engine compartment and luggage compartment (trunk) fuse boxes are identical to those in the Volvo XC90. For detailed diagrams of these locations, refer to the Volvo XC90 fuse box guide.
Passenger Compartment Fuse Box
Located on the driver’s side, at the end edge of the dashboard.
Overview of the Volvo S60 interior fuse panel.
| Diagram | ||
|---|---|---|
|
||
| No. | A | Protected Component / Circuit |
| 1 | 10 | 2000–2002: Left low beam headlight |
| 15 | 2003–2004: Low beam (Bi-Xenon) | |
| 25 | 2005–2009: Power driver seat | |
| 2 | 10 | 2000–2002: Right low beam headlight |
| 20 | 2003–2004: High beam headlights | |
| 25 | 2005–2009: Power passenger seat | |
| 3 | 15 | 2000–2002: Low beam headlights |
| 30 | 2003–2004: Power driver seat | |
| 2005–2009: Climate control blower motor | ||
| 4 | 20 | 2000–2002: High beam headlights |
| 30 | 2003–2004: Power passenger seat | |
| 25 | 2005–2009: Passenger Door Module (PDM) | |
| 5 | 30 | 2000–2002: Power driver seat |
| 15 | 2003–2004: Speed-dependent power steering, vacuum pump | |
| 25 | 2005–2009: Driver Door Module (DDM) | |
| 6 | 30 | 2000–2002: Power passenger seat |
| 5 | 2004 (Bi-Fuel): LPG/CNG cylinder shut-off valve | |
| 10 | 2005–2009: Interior lighting, Rear Control Module (RCM), Upper Electronic Module (UEM) | |
| 7 | 15 | 2000–2004: Heated front left seat |
| 2005–2009: Power sunroof | ||
| 8 | 15 | 2000–2004: Heated front right seat |
| 7.5 | 2005–2009: Ignition switch, SRS (airbag) system, Engine Control Module (ECM), Passenger Airbag Cut-Off Switch (PACOS), Immobilizer (IMMO), Transmission Control Module (TCM — 2006 Diesel & S60 R models) | |
| 9 | 5 | 2000–2004: ABS / STC (2003–2004) / DSTC (2003–2004) |
| 2005–2009: OBD-II diagnostic port, Light Switch Module (LSM), Steering Angle Sensor (SAS), Steering Wheel Module (SWM) | ||
| 10 | 15 | 2000–2002: Left high beam headlight |
| 20 | 2005–2009: Audio system head unit | |
| 11 | 15 | 2000–2002: Right high beam headlight |
| 30 | 2005–2009: Audio system amplifier | |
| 12 | 15 | 2000–2004: Headlight leveling (2004), headlight washer system |
| 10 | 2005–2009: Navigation display (RTI) | |
| 13 | 20 | 2000–2002: 12V power outlet / cigarette lighter |
| 15 | 2003–2004: 12V power outlet / cigarette lighter | |
| 5 | 2005–2009: Integrated phone system | |
| 2005–2009: Positions 14–38 — Not used | ||
| 14 | 5 | Power passenger seat, front seat belt pretensioners (2000–2002) |
| 15 | 5 | 2000–2003: Audio system, Navigation system (VNS) |
| 2004: Audio system, Navigation display (RTI) | ||
| 16 | 20 | Audio system head unit |
| 17 | 30 | Audio system amplifier |
| 18 | 5 | 2000–2002: Front fog lights |
| 15 | 2003–2004: Front fog lights | |
| 19 | 10 | 2000–2003: Navigation system (VNS) |
| 2004: Navigation display (RTI) | ||
| 20 | 5 | 2002: Transport switch |
| 21 | 10 | Automatic transmission control, gear selector lock (shift lock) |
| 22 | 20 | Turn signals / hazard flashers |
| 23 | 5 | Light Switch Module (LSM), Data Link Connector (DLC), Steering Wheel Module (SWM), Climate Control Module (CCM) |
| 24 | 10 | 2000–2002: Climate Control Module (CCM), power driver seat, instrument cluster (DIM) |
| 2003–2004: Climate Control Module (CCM), power driver seat, instrument cluster (DIM), auxiliary parking heater | ||
| 25 | 10 | 2000–2002: Ignition switch, Central Electronic Module (CEM), starter relay |
| 2003: Ignition switch, SRS module, starter relay, Engine Control Module (ECM) | ||
| 2004: Ignition switch, Central Electronic Module (CEM), starter relay, Engine Control Module (ECM) | ||
| 26 | 30 | Climate Control Module (CCM) / Blower motor |
| 27 | 15 | 2000–2002: Driver / Passenger Door Module (DDM/PDM) |
| 2004: Four-C active chassis system | ||
| 28 | 10 | Upper Electronic Module (UEM), interior lighting |
| 29 | 10 | Integrated telephone module |
| 30 | 10 | 2000–2002: Left parking / position lights |
| 7.5 | 2003–2004: Left parking / position lights | |
| 31 | 10 | 2000–2002: Right parking / position lights, license plate lights |
| 7.5 | 2003–2004: Right parking / position lights, license plate lights | |
| 32 | 10 | Central Electronic Module (CEM), vanity mirror lights, speed-dependent power steering, glove box light (2003–2004), interior lighting (2003) |
| 33 | 15 | Volvo S60 fuel pump |
| 34 | 15 | Power sunroof module |
| 35 | 25 | Central locking, power windows, left power mirror |
| 36 | 25 | Central locking, power windows, right power mirror |
| 37 | 30 | Rear power windows, power child locks (2003–2004) |
| 38 | 5 | 2003–2004: Anti-theft alarm siren |
Electronic Control Module Locations
General location diagram of electronic control units (ECUs) and modules throughout the vehicle.
|
|
| No. | Component |
| 1 | Climate Control Module (CCM) / A/C ECU |
| 2 | Blower Motor Control Module — adjacent to the blower motor |
| 3 | Anti-theft inclination sensor (tilt sensor) |
| 4 | Anti-theft alarm siren — behind front right wheel arch liner |
| 5 | Volumetric sensor (anti-theft system) — overhead console |
| 6 | Anti-theft alarm sensor — integrated into Central Electronic Module (CEM) |
| 7 | Audio Control Module (AUM) |
| 8 | Auxiliary heater control module (if equipped) |
| 9 | Battery — under trunk floor |
| 10 | Cruise control system — integrated into Engine Control Module (ECM) |
| 11 | Data Link Connector (DLC / OBD-II port) |
| 12 | Differential Electronic Module (DEM) — rear differential (AWD models) |
| 13 | Driver Door Module (DDM) — in driver door. Controls: Central locking, door ajar status, power/heated door mirrors, power windows, mirror puddle lamps |
| 14 | Passenger Door Module (PDM) — in passenger door. Controls: Central locking, door ajar status, power/heated door mirrors, power windows, mirror puddle lamps |
| 15 | Radiator Cooling Fan Control Module |
| 16 | Engine compartment fuse/relay box 1 |
| 17 | Engine compartment fuse/relay box 2 — located beneath box 1 |
| 18 | Passenger compartment fuse box 1 |
| 19 | Passenger compartment fuse box 2 |
| 20 | Luggage compartment (trunk) fuse box 1 |
| 21 | Luggage compartment (trunk) fuse box 2 — adjacent to battery |
| 22 | Left Headlamp Control Module (HCM) — Xenon/HID headlamps |
| 23 | Right Headlamp Control Module (HCM) — Xenon/HID headlamps |
| 24 | Dual-tone horn |
| 25 | Immobilizer system — integrated into Engine Control Module (ECM) |
| 26 | Immobilizer antenna ring — around ignition switch |
| 27 | Driver Information Module (DIM) — instrument cluster |
| 28 | Light Switch Module (LSM) — behind headlight switch |
| 29 | Central Electronic Module (CEM) — connected to passenger compartment fuse box No. 2. Controls: Anti-theft system, central locking, power windows, windshield wipers/washers, headlight wipers/washers, speed-dependent power steering, immobilizer, headlights, turn signals/hazards, horn, parking lights, starter relay, heated seats, headlight levelling, fuel pump relay, glove box light, high-mount stop light |
| 30 | Rear Electronic Module (REM) — connected to luggage compartment fuse box No. 1. Controls: Anti-theft system, central locking, tail lights, fuel level sender, interior lighting, heated rear window, rear auxiliary power outlet, fuel filter heater (Diesel), power folding rear head restraints |
| 31 | Upper Electronic Module (UEM) — in interior rear-view mirror. Controls: Central locking remote receiver, anti-theft system, power sunroof, rain sensor, interior lighting, seat belt reminder |
| 32 | Navigation Control Module (RTI) |
| 33 | Ambient air temperature sensor — inside right door mirror |
| 34 | Rain sensor (if equipped) |
| 35 | Left door deadlocking relay — inside door |
| 36 | Right door deadlocking relay — inside door |
| 37 | Power Seat Module (PSM) — beneath driver seat |
| 38 | Front left side impact sensor — B-pillar |
| 39 | Front right side impact sensor — B-pillar |
| 40 | Rear left side impact sensor — behind rear seat cushion bolster |
| 41 | Rear right side impact sensor — behind rear seat cushion bolster |
| 42 | Supplemental Restraint System Module (SRS ECM) |
| 43 | Steering Angle Sensor (SAS) module — connected to under-dash fuse box No. 2 |
| 44 | Steering Wheel Module (SWM) — behind steering wheel. Controls: Audio system, cruise control, horn, turn signals, windshield wipers/washers, high/low beam selector, trip computer |
| 45 | Power sunroof control module |
| 46 | Four-C Active Suspension Control Module — beside center console |
| 47 | Transmission Control Module (TCM) |
| 48 | Gear Selector Control Module (GSM) |
| 49 | Telematics Control Module (Volvo On Call / PHM) |
