The second generation Volvo XC90 brings together all the Swedish firm's latest technologies in engine technology, fuel economy and safety. With the change of generations, the model has retained the silhouette of its predecessor, but has become lighter by about 150 kilograms - a benefit of the new platform, which, while reducing weight, offers greater safety at the same time. In this article, we will take a detailed look at the fuse box diagrams for the Volvo XC90 (2Gen; codename L) 2014, 2015, 2016, 2017, 2018, 2019 years of manufacture.
Here you will find the locations and photos of distribution boxes. The fuses responsible for the “Cigarette lighter” and “Fuel Pump” are highlighted in bold.
In the luggage compartment
Located on the right side under the storage compartment.
General view.
| Diagram | ||
|---|---|---|
|
||
| No. | A | Description |
| 1 | 30 | Electrically heated rear window |
| 2 | 20 | Power seat, left rear (Excellence) |
| 3 | 40 | Air suspension compressor |
| 4 | 30 | Electric auxiliary heater, right rear side |
| 5 | - | Reserve |
| 6 | 30 | Electric auxiliary heater, left rear side |
| 7 | 20 | Power seat, right rear (Excellence) |
| 8 | - | Reserve |
| 9 | 25 | Electrically operated tailgate |
| 10 | 20 | Power-operated passenger seat, front |
| 11 | 40 | Towing hook module |
| 12 | 40 | Seat belt pretensioner module, right side |
| 13 | 5 | Internal relay coils |
| 14 | - | Reserve |
| 15 | 5 | Foot movement detection module (for opening the electrically operated tailgate) |
| 16 | - | Reserve |
| 17 | - | Reserve |
| 18 | 25 | Towing hook module |
| 19 | 20 | Electrically operated driver's seat |
| 20 | 40 | Seat belt pretensioner module, left side |
| 21 | 5 | Parking camera |
| 22 | - | Reserve |
| 23 | - | Reserve |
| 24 | 5 | Ionic Air Purifier (Excellence) |
| 25 | - | Reserve |
| 26 | 5 | Airbag and seatbelt pretensioner control module |
| 27 | 10 | Refrigerator (Excellence); Heated / Cooled Rear Cup Holder (Excellence) |
| 28 | 15 | Seat heater, left rear side |
| 29 | - | Reserve |
| 30 | 5 | Blind Spot Information (BUS) |
| 31 | - | Reserve |
| 32 | 5 | Seatbelt pretensioner modules |
| 33 | 5 | Exhaust flap actuator |
| 34 | - | Reserve |
| 35 | 15 | AWD control module |
| 36 | 15 | Seat heater, right rear side |
| 37 | - | Reserve |
| Type Micro: #13-17 and #21-36 MCase type: #1-12, #18-20 and #37 |
||
In the engine compartment
The fuse box is located on the left side behind the protective cover. It consists of two combined boards.
General view of the board #1.
| Diagram | ||
|---|---|---|
|
||
| No. | A | Description |
| 18 | - | Reserve |
| 19 | - | Reserve |
| 20 | - | Reserve |
| 21 | - | Reserve |
| 22 | - | Reserve |
| 23 | 5 | USB port in the front of the tunnel console* |
| 24 | 15 | 12V socket in the front of the tunnel console, Volvo XC90 cigarette lighter fuse |
| 25 | 15 | 12 V socket in the tunnel console, in the footwell of the second row of seats |
| 12V socket in tunnel console between rear seats (Excellence); USB ports in tunnel console between rear seats | ||
| 26 | 15 | 12V socket in luggage compartment |
| USB ports for lpad holder (Excellence) | ||
| 27 | - | Reserve |
| 28 | - | Reserve |
| 29 | - | Reserve |
| 30 | - | Reserve |
| 31 | Shunt | Heated windshield (left side) |
| 32 | 40 | |
| 33 | 25 | Headlight washers |
| 34 | 25 | Windshield washers |
| 35 | - | Reserve |
| 36 | 20 | Horn (beep) |
| 37 | 5 | Security alarm siren |
| 38 | 40 | Brake control module (valves, parking brake) |
| 39 | 30 | Windshield wipers |
| 40 | 25 | Rear window washer |
| 41 | 40 | Heated windshield (right side) |
| 42 | 20 | Parking heater |
| 43 | 40 | Brake control module (ABS pump) |
| 44 | - | Reserve |
| 45 | Shunt | Heated windshield (right side) |
| 46 | 5 | Power is supplied when the ignition is on: Engine control module; Electric servo drive; Transmission components; Central electronic module; Brake system control module |
| 47 | - | Reserve |
| 48 | 7.5 | Right headlight |
| 49 | - | Reserve |
| 50 | - | Reserve |
| 51 | 5 | Module for controlling the battery connection |
| 52 | 5 | Airbags |
| 53 | 7.5 | Left headlight |
| 54 | 5 | Gas pedal position sensor |
| 55 | 15 | Transmission control module |
| 56 | 5 | Engine control module |
| 57 | - | Reserve |
| 58 | - | Reserve |
| 59 | - | Reserve |
| 60 | - | Reserve |
| 61 | 20 | Engine control module; actuator; fuel regulator module; EGR valve (diesel); turbo position sensor (diesel); turbocharger valve (gasoline) |
| 62 | 10 | Solenoids (gasoline); valves; engine cooling thermostat (gasoline); EGR cooling pump (diesel); glow control module (diesel) |
| 63 | 7.5 | Vacuum regulators; valve |
| 64 | 5 | Spoiler louver control module; radiator louver control module |
| 65 | - | Reserve |
| 67 | 15 | Lambda probe, front; lambda probe, rear (gasoline); particulate sensor (diesel) |
| 68 | 15 | Engine oil pump solenoid; air conditioner solenoid clutch; lambda probe, middle (gasoline); lambda probe, rear (diesel) |
| 69 | - | Engine control module |
| 70 | 20 | Ignition coils (gasoline); Spark plugs (petrol) |
| 71 | 15 | Fuel filter heating (diesel) |
| 72 | 30 | Reserve |
| 73 | - | Reserve |
| 74 | - | Reserve |
| 75 | - | Reserve |
| 76 | - | Reserve |
| 77 | Shunt | Starter |
| 78 | 40 | |
| Micro type: #18-30, #35-37, #46-54 and #55-70 MCase type: #31-34, #38-45 and #71-78. |
||
In the passenger compartment
It's located on the passenger side behind the trim.
General view of the Volvo XC90 interior fuse box.
| Diagram | ||
|---|---|---|
|
||
| No. | A | Decryption |
| 1 | - | Spare |
| 2 | 30 | 230 V socket in the tunnel console in the footwell of the second row of seats (Except Excellence) |
| 230 V socket in the tunnel console between the rear seats (Excellence) | ||
| 3 | - | Spare |
| 4 | 5 | Motion Sensor |
| 5 | 5 | Media player |
| 6 | 5 | Driver display |
| 7 | 5 | Set of buttons on the center console |
| 8 | 5 | Sun sensor |
| 9 | - | Spare |
| 10 | - | Spare |
| 11 | 5 | Steering wheel module |
| 12 | 5 | Start handle and parking brake control handle module |
| 13 | 15 | Electrically Heated Steering Wheel Module |
| 14 | - | Spare |
| 15 | - | Spare |
| 16 | - | Spare |
| 17 | - | Spare |
| 18 | 10 | Climate control module |
| 19 | 7.5 | Steering wheel lock |
| 20 | 10 | OBD II diagnostic socket |
| 21 | 5 | Central display |
| 22 | 40 | Front air conditioner fan module |
| 23 | - | Spare |
| 24 | 7.5 | Illumination of controls; |
| Interior lighting; | ||
| Anti-dazzle protection for the inside rearview mirror; | ||
| Rain and light sensor; | ||
| Set of buttons in the tunnel console in the footwell of the second row of seats (Except Excellence); | ||
| Front Power Seats | ||
| Electric rear seats (Excellence); | ||
| Rear seat comfort display (Excellence); | ||
| Comfort function modules for rear seats (massage) (Excellence) | ||
| 25 | 5 | Driver support functions control module |
| 26 | 20 | Panoramic roof with sun blind |
| 27 | 5 | Head-up display |
| 28 | 5 | Interior lighting |
| 29 | - | Spare |
| 30 | 5 | Overhead console display (seat belt reminder / display for front passenger airbag) |
| 31 | - | Spare |
| 32 | 5 | Humidity sensor |
| 33 | 20 | Right rear door module |
| 34 | 10 | Fuses in the cargo area |
| 35 | 5 | Control module for Internet-connected vehicle; telematics module |
| 36 | 20 | Left rear door module |
| 37 | 40 | Audio control unit (amplifier) |
| 38 | 40 | Rear climate control fan module |
| 39 | 5 | Multi-band antenna module |
| 40 | 5 | Comfort function modules for front seats (massage) |
| 41 | - | Spare |
| 42 | 15 | Rear window wiper |
| 43 | 15 | Fuel Pump Control Module (Volvo XC90 Fuel Pump Fuse) |
| 44 | - | Spare |
| 45 | - | Spare |
| 46 | 15 | Heated front seat, driver's side |
| 47 | 15 | Heated front seat, passenger side |
| 48 | 10 | Coolant pump |
| 49 | - | Spare |
| 50 | 20 | Left front door module |
| 51 | 20 | Suspension Control Module (Active Chassis) |
| 52 | - | Spare |
| 53 | 10 | Sensus control module |
| 54 | - | Spare |
| 55 | - | Spare |
| 56 | 20 | Right front door module |
| 57 | 5 | Rear seat comfort display (Excellence equipment) |
| 58 | 5 | TV (some markets) |
| 59 | 15 | Main fuse for #53 and #58 |
